Product Data Sheet PS-00291, Rev. B May 2007 Micro Motion® Series 3000 Transmitters and Discrete Controllers Micro Motion® Series 3000 electronics combine transmitter functions and PLC capabilities in one instrument. Series 3000 models feature MVD™ technology, providing high-speed DSP capabilities and a broad range of specialty applications.
Micro Motion transmitters and controllers Micro Motion transmitters and controllers fit a wide variety of application needs. The table below can help determine which Micro Motion products are right for your process. For more detailed product information, consult the appropriate Product Data Sheet or contact your local Micro Motion representative.
Series 3000 transmitters and discrete controllers MVD technology. MVD technology makes your Micro Motion meter work smarter. Front-end digital processing dramatically reduces signal noise and gives you faster response time compared to analog devices.
Housings Rack-mount 19-inch (486.
Interface/display Display Models 3300 and 3500 Models 3350 and 3700 Keypad membrane switch Backlit LCD, 128 × 128 pixel, bit map Adjustable contrast Non-glare, chemical-resistant acrylic lens Backlit LCD, 128 × 128 pixel, bit map Adjustable contrast Non-glare tempered glass lens Suitable for hazardous area installation Large push buttons with tactile feedback Software-defined function keys Chemical-resistant polyester Electrical connections Input and output connections Rack-mount Type D connectors per
Input signals Non-intrinsically safe input signals One 2-wire Frequency range frequency/pulse input Minimum pulse width Power Voltage Current Two discrete momentary inputs Pulse width Voltage 0–20,000 Hz 25 μ-sec Sourcing or sinking 0–0.8 VDC low state 3–30 VDC high state Nominal 5 mA pull-up 0.15 sec minimum 0–0.
Output signals continued Fault indication When a fault is detected, outputs go to configured states. User can select upscale, downscale, internal zero, or none. Milliamp outputs conform to NAMUR NE43 (June 1994). Upscale Milliamp Frequency 21 to 24 mA, user configurable 15,000 Hz Downscale Milliamp Frequency 1 to 3.
Environmental specifications EMI effects All Series 3000 devices Meet EMC directive 89/336/EEC per EN 61326 Industrial, and all Series 3000 devices conform to NAMUR NE21 (June 1997). Ambient temperature effect On analog outputs ±0.005% of span per °C Ambient temperature limits (1) Operating Storage –4 to +140 °F –40 to +158 °F Temperature accuracy Models 3500 and 3700 ±1.0 °C ±0.5% of reading in °C Temperature repeatability Models 3500 and 3700 ±0.
Hazardous area classifications UL is a U.S.A. approvals agency. CSA is a Canadian approvals agency that provides approvals accepted in both the U.S.A. (C-US) and Canada. ATEX is a European directive. UL and CSA ATEX Model 3300 Class I, Div. 2, Groups A, B, C, and D when installed in a suitable enclosure Model 3350 Class I, Div. 2, Groups A, B, C, and D Model 3500 Class I, Div.
Model 3100 accessory Relays module Three relays Solid state, SPST Rated at 24–250 VAC, 40 mA to 5 A; or 0–70 VDC, 5 A Energized by discrete outputs NEMA 4X (IP65) enclosure (optional) UL and CSA approvals Class I, Div.
Model 3500/3700 density performance (liquid only) Accuracy (1) Repeatability (1) Sensor model g/cm3 kg/m3 ELITE F-Series H-Series ±0.0002 ±0.001 ±0.001 ±0.2 ±1.0 ±1.0 T-Series R-Series ±0.002 Not rated for density ±2.0 ELITE F-Series H-Series T-Series R-Series ±0.0001 ±0.0005 ±0.0005 ±0.0005 Not rated for density ±0.1 ±0.5 ±0.5 ±0.5 (1) For the details of the density accuracy and repeatability specifications, refer to the product data sheet for each sensor family.
Dimensions Rack-mount Model 3300/3500 Dimensions in 1 U = 1 HE = 1.750 inches (44.45 mm) 1 HP = 1 TE = 0.200 inches (5.08 mm) inches (mm) 25 HP (25 TE) 5.0 (127) 4× M2.5 × 11 3U (3 HE) 5 1/16 (128.5) 4 13/16 (122.5) 28 HP (28 TE) 5 9/16 (142.2) 19″ (486.
Dimensions continued Panel-mount Model 3300/3500 with screw-type connectors Dimensions in inches (mm) 6 1/2 (165) 8 1/2 (216) Panel 7 3/4 (197) Frame Bezel 4 1/2 (114) 6 (152) 6 11/16 (170) Approvals tag 6 (152) Intrinsic safety barrier (Model 3500 only) 1/2 (12) Micro Motion® Series 3000 Transmitters and Discrete Controllers 13
Dimensions continued Panel-mount Model 3300/3500 with optional I/O cable Dimensions in inches (mm) 6 1/2 (165) Panel 8 3/4 (222) Frame Bezel 5 5/16 (135) 6 (152) 6 11/16 (170) Approvals tag Minimum 4 1/4″ (108 mm) bend radius 6 (152) 1/2 (12) 3 3/64 (77) 9 (229) 2 31/64 (63) 2 37/64 (66) 14 2 1/4 (57) DIN-rail-mount screw terminals detail 2 15/64 (57) 2 19/64 (59) DIN rail type TS 15 DIN rail type TS 32 DIN rail type TS 35 × 7.
Dimensions continued Field-mount Model 3350/3700 inches (mm) Dimensions in 11 (279) 5 1/16″ (129 mm) Minimum clearance for removal of circuit boards 12 (305) 4× ø 5/16 (9) 9 3/16 (234) 2 13/16 (71) Approvals tag 4 (102) 11 5/16 (288) 6 1/8 (156) Mounting bracket can be rotated 90° 3 5/8 (92) Display/cover can be rotated 90° or 180° 6 (152) 8 11/16 (221) 15 1/2 (394) 4× M8 × 16 bolts are included for attaching the mounting bracket to the Model 3350 or 3700 transmitter 1 7/8 (48) 2× 2 13/16 (71
Ordering information — Model 3300 Model Product description 3300 Micro Motion Coriolis Discrete Controller; remote rack/panel-mount Code Mounting options R DIN rack P Panel-mount Code Power supply options 1 85 to 265 VAC 2 18 to 30 VDC (recommended for 24 VDC users) Code Communication gateway module A No communication gateway module Code Additional hardware modules 0 No additional hardware modules 1 (1) Weights & Measures Custody Transfer (all other than OIML) 2 Weights & Measures
Ordering information — Model 3300 continued Code Language A English local display Danish quick reference guide D English local display Dutch quick reference guide English manual E English local display English quick reference guide English manual F French local display French quick reference guide French manual G German local display German quick reference guide German manual H English local display Finnish quick reference guide English manual I English local display Italian quick
Ordering information — Model 3350 Model Product description 3350 Micro Motion Coriolis Discrete Controller; remote field-mount Code Mounting options A Field-mount Code Power supply options 1 85 to 265 VAC 2 18 to 30 VDC (recommended for 24 VDC users) Code Communication gateway module A No communication gateway module Code Additional hardware modules 0 No additional hardware modules 1 (1) Weights & Measures Custody Transfer (all other than OIML) 2 Weights & Measures Custody Transfer
Ordering information — Model 3350 continued Code Language A English local display Danish quick reference guide D English local display Dutch quick reference guide English manual E English local display English quick reference guide English manual F French local display French quick reference guide French manual G German local display German quick reference guide German manual H English local display Finnish quick reference guide English manual I English local display Italian quick
Ordering information — Model 3500 Model Product description 3500 Micro Motion Coriolis multivariable transmitter and discrete controller; remote rack/panel-mount Code Mounting options R DIN rack P Panel-mount Code Power supply options 1 85 to 265 VAC 2 18 to 30 VDC (recommended for 24 VDC users) Code Remote core processor Sensor interface code 5 A None Sensor interface code 6 (remote core processor) B 1/2″–NPT remote core processor — no gland E M20 remote core processor — no gland F
Ordering information — Model 3500 continued Code Language A English local display Danish quick reference guide D English local display Dutch quick reference guide English manual E English local display English quick reference guide English manual F French local display French quick reference guide French manual G German local display German quick reference guide German manual H English local display Finnish quick reference guide English manual I English local display Italian quick
Ordering information — Model 3700 Model Product description 3700 Micro Motion Coriolis multivariable transmitter and discrete controller; remote field-mount Code Mounting options A Field-mount Code Power supply options 1 85 to 265 VAC 2 18 to 30 VDC (recommended for 24 VDC users) Code Remote core processor A None Sensor interface code 5 Sensor interface code 6 (remote core processor) B 1/2″–NPT remote core processor — no gland E M20 remote core processor — no gland F Remote core proc
Ordering information — Model 3700 continued Code Language A English local display Danish quick reference guide D English local display Dutch quick reference guide English manual E English local display English quick reference guide English manual F French local display French quick reference guide French manual G German local display German quick reference guide German manual H English local display Finnish quick reference guide English manual I English local display Italian quick
Ordering information — Model 3100 high energy relay Model Product description 3100 Micro Motion Coriolis High Energy Relay Code Device (order separately) A 3 relays; 24–250 VAC; 5 A B 3 relays; 0–70 VDC; 5 A Code Housing 1 No housing 2 (1) NEMA 4X housing for relays only Code Future expansion A Reserved for future use Code Approvals M Micro Motion standard (no approval) U UL Class I, Div. 2, Groups A, B, C, and D C CSA Class I, Div.
Micro Motion® Series 3000 Transmitters and Discrete Controllers 25
Micro Motion® Series 3000 Transmitters and Discrete Controllers
Micro Motion® Series 3000 Transmitters and Discrete Controllers 27
Micro Motion—The undisputed leader in flow and density measurement World-leading Micro Motion measurement solutions from Emerson Process Management deliver what you need most: Technology leadership Micro Motion introduced the first reliable Coriolis meter in 1977. Since that time, our ongoing product development has enabled us to provide the highest performing measurement devices available.
