4.4.2LugSizeTable(perphase)
Three-Phase
Input Output
208/240V 480/600V 208/240V 480/600V
20 #10-1/0 #10-1/0 #14-2/0 #14-2/0
30 #14-4/0 #10-1/0 #14-2/0 #14-2/0
50 #14-4/0 #10-1/0 #14-2/0 #14-2/0
75 #14-4/0 #10-1/0 (2) #6-350 #14-2/0
NOTE:AlllugsacceptAI/Cuwire.
4.5 Startup
Power may be applied to the unit AFTER the following conditions have been met:
•All power and ground cable connections have been secured.
•The enclosure has been closed.
•The circuit breaker operating mechanism is in the OFF (open) position. The
smaller, auxiliary circuit breakers should be in the ON (closed) position.
5.0 Diagnostics
5.1IndicatorLights
The unit contains 3 indicator lights on the front panel and a remote alarm relay.
5.1.1GreenLight
Condition normal. The remote alarm relay is open.
5.1.2MiddleAmberLight
A transformer over-temperature has been detected. The output voltage is not
regulated under this condition in order to minimize transformer losses. The
remote alarm relay is closed. In order to reset this condition, the unit must be
turned off, allowed to return to normal temperature, and then turned back on.
Check to ensure the load kVA does not exceed the nameplate kVA. Make sure
the ambient temperature does not exceed 40°C.
5.1.3RightAmberLight
TheunithasgoneintobypassduetoafailedSCRorringboardmalfunction.
Under this condition the unit will not regulate the output voltage. The remote
alarmrelayisclosed;theunitneedstobereset.(See“5.1.4”.)Aqualiedelectri-
cian should determine whether there is a permanent problem.
