Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-60 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
R
AUDIBLE SILENT TIME
= mm MINUTES
or
AUDIBLE ALARMS STAY
SILENCED
Initialization
Menu
Allows you to enable the MCA Audible Alarm
feature and set the Audible Alarm Cutoff Reset
Time Period set point, or disable the feature.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
NO / - when in the change setting
mode to scroll to AUDIBLE ALARMS
STAY SILENCED (displayed when you
scroll down to "zero minutes").
S
PCU SEQUENCING IS
DISABLED
or
PCU SEQUENCING DELAY
= ss SECONDS
Initialization
Menu
Allows you to enable the Rectifier Sequencing
feature and set the Rectifier Sequencing Delay
set point, or disable the feature.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
NO / - when in the change setting
mode to scroll to Rectifier
SEQUENCING IS DISABLED
(displayed when you scroll down to
"zero seconds").
T
TEST EQUALIZE IS DISABLED
TURN OFF POWER SHARE
or
MANUAL TEST/EQUALIZE
= hh HOURS
or
TEST/EQUALIZE STOP
IS MANUAL
Initialization
Menu
Allows you to enable the Manual Timed
Test/Equalize feature and set the Timed
Test/Equalize set point, or disable the feature.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
NO / - when in the change setting
mode to scroll to TEST/EQUALIZE
STOP IS MANUAL (displayed when
you scroll down to "zero hours"). This
indicates the manually initiated timed
test/equalize feature is disabled and
the system must be manually returned
to the float mode if placed in the
test/equalize mode.
When the Power Share feature is enabled, the
system cannot be placed in the Test/Equalize
mode.
Note: Test/Equalize Mode requires Power
Share to be turned off. A message is displayed
if Power Share is on. Turn Power Share off
first then return to this menu.
