Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-52 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
372
PCU B#-SN#
LOAD SHARE
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) event.
373
PCU B#-SN#
1 FAN SPEED
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) event.
374
PCU B#-SN#
2+ FANS SPEED
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) event.
375
PCU B#-SN#
NO VOLT SENSE
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) event.
376
PCU B#-SN#
DUPLICATED
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) event.
377
PCU B#-SN#
NO RESPONSE
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) event.
378
PCU B#-SN#
TURNED ON
or
PCU B#-SN#
TURNED OFF
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) Data.
379
PCU B#-SN#
aaaaaA
PCU
Alarm Log
Detail Menu
Recordable Rectifier Module (PCU) Data.
380
SYSTEM OUTPUT SENSE
vv.vvV
PCU
Alarm Log
Detail Menu
Recordable System Data.
381
TOTAL LOAD CURRENT
aaaaaA
PCU
Alarm Log
Detail Menu
Recordable System Data.
382
GO TO ALARM LOG MENU
PCU
Alarm Log
Detail Menu
Press ENTER to go to this menu.
383
GO BACK TO MENU TREE
BEGINNING
PCU
Alarm Log
Detail Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
384
dd-mon-yy hh:mm:ss♪
PANEL B#-P#A/B
or
dd-mon-yy hh:mm:ss
PANEL B#-P#A/B
Alarm Log
Menu
Displays the alarms (with date and time stamp)
recorded for the Distribution Panel element of
the system.
Press UP and DOWN ARROWS to scroll if
multiple alarms are recorded.
A 'music note' (♪) after the date/time stamp
indicates the alarm went active. A 'checkmark'
() indicates the alarm retired.
