User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 2. Navigating the MCA Page 2-49
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
328A
ALTERNATE CURRENT
LIMIT ACTIVE
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
329
SYSTEM VOLTAGE IS
VERY LOW
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
330
SYSTEM BATTERY IS ON
DISCHARGE
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
331
SYSTEM HIGH VOLTAGE
#1 ALARM
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
332
SYSTEM HIGH VOLTAGE
#2 ALARM
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
333
NO PCUs ARE
IN INVENTORY
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
334
NO DIST. PANELS ARE
IN INVENTORY
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
335
NO ROUTERS ARE
IN INVENTORY
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
336
NO RELAY BOARDS ARE
IN INVENTORY
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
337
HIGH TEMPERATURE #1
ALARM
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
338
HIGH TEMPERATURE #2
ALARM
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
339
LOW TEMPERATURE #1
ALARM
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
340
LOW TEMPERATURE #2
ALARM
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
341
TEMPERATURE SENSOR
NO SIGNAL
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
342
MAJOR MONITORING
ALARM(S)
MCA
Alarm Log
Detail Menu
Recordable MCA (Controller) event.
