User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 2. Navigating the MCA Page 2-45
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
310
START RELAY FUNCTION
TEST
or
TIME PER FUNCTION
= hh:mm:ss
or
TIME PER FUNCTION
NO TIMEOUT
or
AUTOMATICALLY TEST
ALL FUNCTIONS
or
TEST RELAY FUNCTION
A#
or
STOP RELAY FUNCTION
TEST
or
TESTING FUNCTION A#
= hh:mm:ss
or
TESTING FUNCTION A#
NO TIMEOUT
Configure
Menu
Set, activate, monitor, or stop the progress of
the MCA Customer Alarm Relay Test Feature.
1. With START RELAY FUNCTION TEST
being displayed, press ENTER and
ALARM CUTOFF (at the same time).
2. Press the UP and DOWN ARROWS to
select a time period for each Relay
Function Channel test or select NO
TIMEOUT.
3. Press ENTER.
4. Press the UP and DOWN ARROWS to
select either AUTOMATICALY TEST
ALL FUNCTIONS (to test all relay
function channels), or TEST RELAY
FUNCTION A# (to test an individual
relay function channel).
5. Press ENTER.
6. To start the Relay Function Test; press
the UP ARROW, to cancel press the
DOWN ARROW.
7. The Relay Function being tested and
the remaining time are displayed.
8. To terminate the test, press ENTER
and ALARM CUTOFF (at the same
time) until STOP RELAY FUNCTION
TEST is displayed.
9. To stop the test, press UP ARROW.
To keep the test running, press DOWN
ARROW.
10. At the "ARE YOU SURE?" prompt,
press YES / + / i.
311
ASSIGN RELAYS TO
FUNCTIONS
Configure
Menu
Allows you to configure a relay by assigning a
Relay Function Channel to a specific relay.
Press ENTER to assign relays to functions.
312
ASSIGN RELAY B#-P#-R#
FUNCTION A#
Relay
Assignment
Menu
Select the MCA Customer Alarm Relay to be
configured, and assign a relay function channel
to this relay.
1. Press the UP and DOWN ARROWS to
navigate to the desired relay.
(B#-P#-R# = Bay Number-MCA
Customer Alarm Relay Circuit Card
Position Number-Relay Number).
2. Refer to "Changing a Value or Setting"
in the table at the beginning of this
document to complete the operation.
Note: See the table in Section 5876
(Installation Instructions) for the MCA default
configuration.
