Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-42 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
296
MINOR MONITORING
ALARM(S)
or
MINOR MONITORING
ALARM(S)
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: If any of these LMS1000 conditions are
selected to contribute to an MCA alarm, the
User must ensure that the LMS1000 is
programmed so that the MCA does not
contribute to the LMS1000 condition.
297
All Monitoring LED
Messages
or
All Monitoring LED
Messages
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: If any of these LMS1000 conditions are
selected to contribute to an MCA alarm, the
User must ensure that the LMS1000 is
programmed so that the MCA does not
contribute to the LMS1000 condition.
298
MONITORING DOES NOT
RESPOND
or
MONITORING DOES NOT
RESPOND
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
299
CONTROLLER FAILURE
or
CONTROLLER FAILURE
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
