Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-38 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
275
1 PCU FAILURE
'MINOR' TYPE
or
1 PCU FAILURE
'MINOR' TYPE
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: Thermal Current Limit, 1 Fan Failure,
High Ambient Temperature, and Sense Loss
are 'Minor' alarm conditions. All other Rectifier
Module alarms are 'Major' alarm conditions.
276
2+ PCU FAILURES
'MINOR' TYPE
or
2+ PCU FAILURES
'MINOR' TYPE
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: Thermal Current Limit, 1 Fan Failure,
High Ambient Temperature, and Sense Loss
are 'Minor' alarm conditions. All other Rectifier
Module alarms are 'Major' alarm conditions.
277
NO PCUs ARE
IN INVENTORY
or
NO PCUs ARE
IN INVENTORY
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
278
1 DIST. PANEL
FAILURE
or
1 DIST. PANEL
FAILURE
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
279
2+ DIST. PANEL
FAILURES
or
2+ DIST. PANEL
FAILURES
Relay
Function
Definition
Menu
This condition is selected when the
(checkmark) symbol is displayed.
This condition is deselected when a space is
displayed instead of the (checkmark)
symbol.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
