User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 2. Navigating the MCA Page 2-33
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
253
TEST EQUALIZE IS DISABLED
or
MANUAL TEST/EQUALIZE
= hh HOURS
or
TEST/EQUALIZE STOP
IS MANUAL
or
END TEST/EQUALIZE IN
hh.hh HOURS
or
TURN OFF POWER SHARE
or
TURN OFF ALTERNATE
CURRENT LIMIT
Configure
Menu
Allows you to enable the Manual Timed
Test/Equalize feature and set the Timed
Test/Equalize set point, or disable the feature.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
NO / - when in the change setting
mode to scroll to TEST/EQUALIZE
STOP IS MANUAL (displayed when
you scroll down to "zero hours"). This
indicates the manually initiated timed
test/equalize feature is disabled and
the system must be manually returned
to the float mode if placed in the
test/equalize mode.
or
If manually initiated timed test/equalize feature
is enabled and the system is placed in the
test/equalize mode (via the MCA interface),
remaining test/equalize time is displayed.
Note: When TEST/EQUALIZE STOP IS
MANUAL or END TEST/EQUALIZE IN hhh.hh
HOURS is being displayed, press and release
ENTER and ALARM CUTOFF simultaneously
to change the MANUAL TEST/EQUALIZE = hh
HOURS setting.
or
When the Power Share or Alternate Current
Limit feature is enabled, the system cannot be
placed in the Test/Equalize mode.
Note: Test/Equalize Mode requires Power
Share and Alternate Current Limit to be turned
off. A message is displayed if Power Share or
Alternate Current Limit is on. Turn Power
Share or Alternate Current Limit off first then
return to this menu.
