Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-30 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
238
GO BACK TO MENU TREE
BEGINNING
Alarm
Adjustment
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
239
TURN PCUs ON OR OFF
or
ENERGY MANAGEMENT IS
IN CONTROL
Function
Menu
Press ENTER to go to the Rectifier Module
(PCU) Enable Menu.
240
PCU B#-ID#/N# ON
TURN IT OFF?
or
PCU B#-ID#/N# OFF
TURN IT ON?
or
ENERGY MANAGEMENT
IN CONTROL
PCU
Enable Menu
Allows you to turn a Rectifier Module (PCU)
ON or OFF (Local TR inhibit feature).
1. Press the UP and DOWN ARROWS to
navigate to the Rectifier Module to turn
ON or OFF (B#-ID#/N# = Bay Number-
Rectifier Module MCA ID# w/in
Bay/Number of Rectifier Modules in
System).
2. Press ENTER and ALARM CUTOFF
(at the same time) to change the TR
setting for this Rectifier Module.
3. At the "ARE YOU SURE?" prompt,
press either YES / + / i to accept the
new setting, or NO / - to cancel this
operation without changing the existing
setting.
Note: Rectifier Modules cannot be turned on
or off if energy management is active.
241
GO TO FUNCTION MENU
PCU
Enable Menu
Press ENTER to go to this menu.
242
GO BACK TO MENU TREE
BEGINNING
PCU
Enable Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
243
CHANGE CONFIGURATION
PARAMETERS
Function
Menu
Press ENTER to go to the Configure Menu.
244
CHANGE I/O BOARD
PARAMETERS
Configure
Menu
Allows you to change the MCA I/O circuit
card(s) configurable parameters.
Press ENTER to configure the MCA I/O circuit
cards.
