User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 2. Navigating the MCA Page 2-29
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
233
HIGH TEMPERATURE #1
= ttt C/F
or
NO HIGH TEMPERATURE
#1 ALARM
Alarm
Adjustment
Menu
Allows you to change the High Temperature #1
Alarm set point, or disable the alarm.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
YES / + / i when in the change setting
mode to scroll to NO HIGH
TEMPERATURE #1 ALARM
(displayed when you scroll up to
"100 C").
234
HIGH TEMPERATURE #2
= ttt C/F
or
NO HIGH TEMPERATURE
#2 ALARM
Alarm
Adjustment
Menu
Allows you to change the High Temperature #2
Alarm set point, or disable the alarm.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
YES / + / i when in the change setting
mode to scroll to NO HIGH
TEMPERATURE #2 ALARM
(displayed when you scroll up to
"100 C").
235
LOW TEMPERATURE #1
= ttt C/F
or
NO LOW TEMPERATURE
#1 ALARM
Alarm
Adjustment
Menu
Allows you to change the Low Temperature #1
Alarm set point, or disable the alarm.
1. Refer to "Changing a Value or
Setting" in the table at the
beginning of this chapter.
Note: To disable the feature, press
NO / - when in the change setting
mode to scroll to NO LOW
TEMPERATURE #1 ALARM
(displayed when you scroll down to
"-50 C").
236
LOW TEMPERATURE #2
= ttt C/F
or
NO LOW TEMPERATURE
#2 ALARM
Alarm
Adjustment
Menu
Allows you to change the Low Temperature #2
Alarm set point, or disable the alarm.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
Note: To disable the feature, press
NO / - when in the change setting
mode to scroll to NO LOW
TEMPERATURE #2 ALARM
(displayed when you scroll down to
"-50 C").
237
GO TO FUNCTION MENU
Alarm
Adjustment
Menu
Press ENTER to go to this menu.
