User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 2. Navigating the MCA Page 2-25
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
201
CONTROLLER SERIAL #
####################
Controller
Detail Menu
Serial number of the MCA/Router circuit card.
202
CONTROLLER BOOTCODE
####################
Controller
Detail Menu
Software bootcode version number of the
MCA/Router circuit card.
203
CONTROLLER SOFTWARE
####################
Controller
Detail Menu
Software version number of the MCA/Router
circuit card.
204
DISPLAY ASSEMBLY
####################
Controller
Detail Menu
Specification number (Spec. No.) of the Display
circuit card.
205
DISPLAY SERIAL #
####################
Controller
Detail Menu
Serial number of the Display circuit card.
206
DISPLAY BOOTCODE
####################
Controller
Detail Menu
Software bootcode version number of the
Display circuit card.
207
DISPLAY SOFTWARE
####################
Controller
Detail Menu
Software version number of the Display circuit
card.
208
GO TO INVENTORY MENU
Controller
Detail Menu
Press ENTER to go to this menu.
209
GO BACK TO MENU TREE
BEGINNING
Controller
Detail Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
210
UPDATE THE INVENTORY
Inventory
Menu
Allows resetting the inventory count when an
inventory item is removed from the system by
the user.
When an inventory item is removed from
the system, an alarm will be reported until
"UPDATE THE INVENTORY" is entered.
Example, if a Rectifier Module (PCU) is
removed from the system, the Rectifier
Module will not be removed from the
MCA's inventory until "UPDATE THE
INVENTORY" operation is completed.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
211
GO TO FUNCTION MENU
Inventory
Menu
Press ENTER to go to this menu.
212
GO BACK TO MENU TREE
BEGINNING
Inventory
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
213
ADJUST THE SYSTEM
VOLTS & AMPS
Function
Menu
Press ENTER to go to the System Adjustment
Menu.
214
FLOAT SETPOINT
= vv.vvV
System
Adjustment
Menu
Allows you to change the Float Output Voltage
set point.
1. Refer to "Changing a Value or Setting"
in the table at the beginning of this
chapter.
