User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 2. Navigating the MCA Page 2-23
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
177
ROUTER B# BOOTCODE
####################
Router
Inventory
Detail Menu
Router Bootcode Number.
(B# = Bay Number).
178
ROUTER B# SOFTWARE
####################
Router
Inventory
Detail Menu
Router Software Number.
(B# = Bay Number).
179
GO TO ROUTER
INVENTORY
Router
Inventory
Detail Menu
Press ENTER to go to this menu.
180
GO BACK TO MENU TREE
BEGINNING
Router
Inventory
Detail Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
181
1 RELAY BOARD IS
REPORTING
or
## RELAY BOARDS ARE
REPORTING
or
NO RELAY BOARDS ARE
INSTALLED
Inventory
Menu
Number of MCA Customer Alarm Relay Circuit
Cards in MCA inventory.
Press ENTER to view individual MCA
Customer Alarm Relay Circuit Card inventory
information.
or
No MCA Customer Alarm Relay Circuit Cards
installed.
182
RELAY BOARD B#-P# IS
INSTALLED
Relay
Inventory
Menu
MCA Customer Alarm Relay Circuit Card
identification number. (B#-P# = Bay Number-
Relay Circuit Card Position Number).
Press UP and DOWN ARROWS to view other
MCA Customer Alarm Relay Circuit Cards'
identification numbers.
183
GO TO INVENTORY MENU
Relay
Inventory
Menu
Press ENTER to go to this menu.
184
GO BACK TO MENU TREE
BEGINNING
Relay
Inventory
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
185
BOARD B#-P# ASSEMBLY
####################
Relay
Inventory
Detail Menu
MCA Customer Alarm Relay Circuit Card
Assembly Number. (B#-P# = Bay
Number-MCA Customer Alarm Relay Circuit
Card Position Number).
186
BOARD B#-P# SERIAL #
####################
Relay
Inventory
Detail Menu
MCA Customer Alarm Relay Circuit Card Serial
Number. (B#-P# = Bay Number-MCA
Customer Alarm Relay Circuit Card Position
Number).
187
BOARD B#-P# BOOTCODE
####################
Relay
Inventory
Detail Menu
MCA Customer Alarm Relay Circuit Card
Bootcode Number. (B#-P# = Bay
Number-MCA Customer Alarm Relay Circuit
Card Position Number).
