Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-22 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
164
GO BACK TO MENU TREE
BEGINNING
I/O Board
Inventory
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
165
BOARD B#-P# ASSEMBLY
####################
I/O Board
Inventory
Detail Menu
MCA I/O Circuit Card Assembly Number.
(B#-P# = Bay Number-MCA I/O Circuit Card
Position Number).
166
BOARD B#-P# SERIAL #
####################
I/O Board
Inventory
Detail Menu
MCA I/O Circuit Card Serial Number.
(B#-P# = Bay Number-MCA I/O Circuit Card
Position Number).
167
BOARD B#-P# BOOTCODE
####################
I/O Board
Inventory
Detail Menu
MCA I/O Circuit Card Bootcode Number.
(B#-P# = Bay Number-MCA I/O Circuit Card
Position Number).
168
BOARD B#-P# SOFTWARE
####################
I/O Board
Inventory
Detail Menu
MCA I/O Circuit Card Software Number.
(B#-P# = Bay Number-MCA I/O Circuit Card
Position Number).
169
GO TO I/O BOARD
INVENTORY
I/O Board
Inventory
Detail Menu
Press ENTER to go to this menu.
170
GO BACK TO MENU TREE
BEGINNING
I/O Board
Inventory
Detail Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
171
1 ROUTER IS
REPORTING
or
## ROUTERS ARE
REPORTING
or
NO ROUTERS ARE
INSTALLED
Inventory
Menu
Number of Router Circuit Cards in MCA
inventory.
Press ENTER to view individual Router Circuit
Card inventory information.
or
No Router Circuit Cards installed.
172
ROUTER B# IS
INSTALLED
Router
Inventory
Menu
Router Circuit Card identification number. (B#
= Bay Number).
Press UP and DOWN ARROWS to view other
Router Circuit Cards' identification numbers.
173
GO TO INVENTORY MENU
Router
Inventory
Menu
Press ENTER to go to this menu.
174
GO BACK TO MENU TREE
BEGINNING
Router
Inventory
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
175
ROUTER B# ASSEMBLY
####################
Router
Inventory
Detail Menu
Router Assembly Number.
(B# = Bay Number).
176
ROUTER B# SERIAL #
####################
Router
Inventory
Detail Menu
Router Serial Number.
(B# = Bay Number).
