Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-16 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
106
SYSTEM OUTPUT SENSE
vv.vvV (REM)
or
SYSTEM OUTPUT SENSE
vv.vvV (AVG)
Measurement
Menu
The voltage of the external (remote) source
connected to the MCA / Router circuit card (for
MCA alarms and meter reading), if connected.
or
System output sense voltage (average of all
bay's internal sense voltages).
Press ENTER to view individual bay sense
voltages.
107
ROUTER B# REMOTE
SENSE vv.vvV
Router
Voltage
Menu
External (remote) sense voltage applied to the
MCA / Router Circuit Card, if connected. (B# =
Bay Number).
Press UP and DOWN ARROWS to view other
Router Circuit Cards' sense voltages.
108
ROUTER B# INTERNAL
SENSE vv.vvV
Router
Voltage
Menu
Internal sense voltage applied to the Router
Circuit Card. (B# = Bay Number).
Press UP and DOWN ARROWS to view other
Router Circuit Cards' sense voltages.
109
GO TO MEASUREMENT
MENU
Router
Voltage
Menu
Press ENTER to go to this menu.
110
GO BACK TO MENU TREE
BEGINNING
Router
Voltage
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
111
TOTAL SYSTEM
LOAD aaaaaA
Measurement
Menu
Total system load current.
112
TOTAL DISTRIBUTION
LOAD aaaaaA
or
TOTAL AUXILIARY
LOAD aaaaaA
System
Load Menu
Total distribution load current (includes
distribution loads monitored by the Distribution
Bus Monitoring Circuit Cards and any MCA I/O
Circuit Card set as "Distribution" [other setting
choice is "Auxiliary"]).
Press ENTER to view individual bay
distribution load currents.
or
Total (sum) load current monitored by MCA I/O
Circuit Cards set as "Auxiliary".
Press ENTER to view individual MCA I/O
circuit card load currents.
113
DISTRIBUTION GROUP A
LOAD aaaaaA
System
Load Menu
Total load current monitored by Distribution
Bus Monitoring Circuit Cards set as Group A
designation.
114
DISTRIBUTION GROUP B
LOAD aaaaaA
System
Load Menu
Total load current monitored by Distribution
Bus Monitoring Circuit Cards set as Group B
designation.
115
REMOTE SYSTEM
LOAD aaaaaA
System
Load Menu
Total Remote Distribution load current reported
by the LMS when LMS Function Channel 63
value is greater than zero.
