Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 2-12 Chapter 2. Navigating the MCA
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Menu
Tree Line No.
(Section
5886)
Message Displayed
Associated
with ...
Definition
59
Binary Input Customer
Text Message
I/O Board
Alarm Detail
Menu
Custom test message stored in MCA for binary
input that is in alarm state. If multiple inputs in
alarm state, scroll through each.
Note: Refer to System Operating Procedures
chapter in Section 5877 for procedure how to
enter custom test messages. Refer to
Installing the Rectifier Modules and Initially
Starting the Power System chapter in Section
5876 for procedure how to program binary
input alarm state (either open or close contact
state).
60
I/O BOARD B#-P#
OVER CURRENT
I/O Board
Alarm Detail
Menu
If the current reflected by the analog inputs or
outputs gets up to 95% of the shunt rating, the
I/O board activates an over current alarm.
(B#-P# = Bay Number-MCA I/O Circuit Card
Position Number.)
61
I/O BOARD B#-P#
PROCESSOR
I/O Board
Alarm Detail
Menu
MCA I/O Circuit Card's processor failed.
(B#-P# = Bay Number-MCA I/O Circuit Card
Position Number.)
62
I/O BOARD B#-P# IS
DUPLICATED
I/O Board
Alarm Detail
Menu
Duplicated Reference Designations.
63
I/O BOARD B#-P#
NO RESPONSE
I/O Board
Alarm Detail
Menu
MCA communications with MCA I/O Circuit
Card lost. (B#-P# = Bay Number-MCA I/O
Circuit Card Position Number.)
64
GO TO I/O BOARD
ALARM MENU
I/O Board
Alarm Detail
Menu
Press ENTER to go to this menu.
65
GO BACK TO MENU TREE
BEGINNING
I/O Board
Alarm Detail
Menu
Press ENTER to go to the beginning of the
MCA Menu Tree.
66
1 ROUTER
HAS FAILED
or
## ROUTERS
HAVE FAILED
or
NO ROUTERS ARE
IN INVENTORY
Main
Alarm Menu
One or more Router Circuit Cards failed. (## =
number of failed Router Circuit Cards.)
Press ENTER to view which Router Circuit
Card(s) failed.
or
If the MCA does not recognize any Router
Circuit Card, NO ROUTERS ARE IN
INVENTORY is displayed.
67
ROUTER B#
FAILURE
Router
Alarm Menu
Identification of failed Router Circuit Card. (B#
= Bay Number.)
Press UP and DOWN ARROWS to scroll if
multiple Router Circuit Cards failed.
Press ENTER to view why Router Circuit Card
failed.
68
GO TO MAIN ALARM
MENU
Router
Alarm Menu
Press ENTER to go to this menu.
