Detail I6 - LMS 4 Output Relay Circuit Card (P/N 506335)
Relay output wiring
connection terminals
Note:
Relay designations K1 through K4 as shown are for the
circuit card only. The actual relay channel number depends
upon the number of relay circuit cards installed and the
location of this relay circuit card in the system network.
LMS 4-OUTPUT RELAY
CIRCUIT CARD (P/N 506335)
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
NC
C
NO
TB1
506335
NC
C
NO
NC
C
NO
NC
C
NO
K4
K3
K2
K1
Relay contacts are shown with the relays deenergized.
