Detail I4 - LMS 4 Input Binary Circuit Card (P/N 506332)
Binary input
wiring connection
terminals
Note:
Binary input designations B1 through B4 as shown are for
the circuit card only. The actual binary channel number
depends upon the quantity of binary circuit cards installed
and the location of this binary circuit card in the
system network.
LMS 4-INPUT BINARY
CIRCUIT CARD (P/N 506332)
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
B4
TB1
506332
B3
B2
B1
