Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 6-10 Chapter 6. System Troubleshooting and Repair
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Figure 6-1
208V and 480V Rectifiers
SAFETY LATCH
LATCH RELEASE
OBSERVE
INSTRUCTIONS
ON TOP OF PCU AS
PCU IS REMOVED
MUST HAVE CONTROL
OF PCU WHEN LINE
REACHES EDGE OF BAY
MUST HAVE CONTROL
OF PCU WHEN LINE
REACHES EDGE OF BAY
MUST HAVE CONTROL OF
PCU WHEN LINE REACHES
FRONT OF ADJACENT PCU
GRASP SIDE IN THIS
AREA TO CARRY
OR REMOVE PCU.
GRASP SIDE IN THIS
AREA TO CARRY
OR REMOVE PCU.
CENTER OF
GRAVITY AREA
SPRING LATCH ON LEFT
SIDE OF PCU MUST BE
DEPRESSED TO REMOVE
THE PCU FROM THE BAY.
CAUTION:
WEIGHT 40 LBS (18.1kG)
ATTENTION:
