SETTING MCA CUSTOM TEXT MESSAGES (NAMES)
You can set a custom text message (name) to be displayed for the following MCA
items…
MCA, Router (Bay), Rectifier, Distribution Bus, Individual Distribution Points, MCA
Customer Alarm Relay Cards, Individual MCA Relays, MCA I/O Card Binary Alarms.
Whenever the MCA is displaying specific information pertaining to a specific MCA item,
an i (information available) is also displayed on the fourth line. Pressing the FUNCTION
SET YES (+) (i) key toggles the name of the displayed MCA item between the normal
MCA naming convention and a custom test message (if set).
To enter or change a custom text message, perform the following procedure.
Procedure
1) Navigate to an MCA menu item that displays information about the particular
MCA item you want to set a custom text message for. Note that the i is displayed
on the fourth line.
2) Press the FUNCTION SET YES (+) (i) key to display the text message.
3) Press and release the ALARM CUTOFF and FUNCTION SET ENTER keys
simultaneously.
4) An underline appears below the first character. Repeatedly, press and release
the FUNCTION SET YES (+) or NO (-) keys to enter the desired character.
5) Press the FUNCTION SET ENTER key to lock the character and to move to the
next character.
6) You can enter up to 32 characters for the custom text message in this fashion. If
the custom text message contains less then 32 characters, simply repeatedly
press the FUNCTION SET ENTER key until you exit the text change mode.
