Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 3-16 Chapter 3. System Operating Procedures
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Method 4 (External Test/Equalize) Procedure
In this method, a user (or external equipment) places the system in the test/equalize
mode by applying an external signal to the system. The system returns to the float mode
when the external signal is removed. This method overrides the other three methods.
Placing the System into Test/Equalize Mode: Apply an external test/equalize loop
closure to the system's remote equalize terminals.
Returning to Float Mode: Remove the external test/equalize loop closure from the
system's remote equalize terminals.
Note: If a manual test/equalize, manually initiated timed test/equalize ,or automatic
equalize is in process; it is canceled and the system returns to float mode when
system ground is removed from the test/equalize terminal.
