Section 5877 User Instructions
Issue AQ, January 15, 2013 Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B)
Page 3-12 Chapter 3. System Operating Procedures
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Method 2 (Manually Initiated Timed Test/Equalize) Procedure
In this method, a user manually places the system into the test/equalize mode via the
MCA Control Panel. The system automatically returns to the float mode after a preset
programmable time period (1-99 hours, in increments of one hour). Follow the
procedures described below.
Setting for Manually Initiated Timed Test/Equalize: Set the "MANUAL
TEST/EQUALIZE = hh HOURS" menu item in the MCA configure menu to a value
between 1 and 99. A step-by-step procedure is provided next.
1) With SYSTEM OK being displayed on the MCA Interface Pad, press and release
the FUNCTION SET ENTER key. The FUNCTION MENU is displayed.
or
In the MAIN ALARM MENU, repeatedly press and release the FUNCTION
SELECT DOWN arrow key until "GO TO FUNCTION MENU" is displayed. Press
and release the FUNCTION SET ENTER key. The FUNCTION MENU is
displayed.
2) Repeatedly press and release the FUNCTION SELECT DOWN arrow key until
"CHANGE CONFIGURATION PARAMETERS" is displayed. Press and release
the FUNCTION SET ENTER key.
3) Press and release the FUNCTION SELECT DOWN arrow key to display
"MANUAL TEST/EQUALIZE = hh HOURS" or "TEST/EQUALIZE STOP IS
MANUAL" is displayed.
Note: If "MANUAL TEST/EQUALIZE = hh HOURS" is displayed, the system is
already set for manually initiated timed test/equalize. In this case, you
can proceed with steps 4) through 7) to change the current setting, or
proceed with step 8) if no changes are required.
Note: If "END TEST/EQUALIZE IN hhh.hh HOURS" is displayed, the system is
already set for manually initiated timed test/equalize, and a timed
test/equalize is in progress. In this case, you can proceed with steps 4)
through 7) to cancel the timed test/equalize in progress and change the
current setting, or proceed with step 8) to proceed with the timed
test/equalize in progress and make no changes.
4) Press and release the ALARM CUTOFF and FUNCTION SET ENTER keys
simultaneously.
5) Press the FUNCTION SET YES (+) or FUNCTION SET NO (-) key until the
desired value is displayed, then release the key. Note that as you scroll BELOW
0, "TEST/EQUALIZE STOP IS MANUAL" is displayed. Scroll back up to
redisplay "MANUAL TEST/EQUALIZE =".
6) Press and release the ALARM CUTOFF and FUNCTION SET ENTER keys
simultaneously.
7) “ARE YOU SURE?” is displayed. Press and release the FUNCTION SET YES
(+) key.
8) Press and release the FUNCTION SET YES (+) and NO (-) keys simultaneously,
to return to the beginning of the MCA menu tree.
Placing the System into Test/Equalize Mode: Manually place the system into
test/equalize mode by navigating to and activating the "FLOAT MODE ACTIVE. SET
TEST/EQ?" menu item in the MCA function menu. The system is placed in the
test/equalize mode for the time period set in "MANUAL TEST/EQUALIZE = hh HOURS".
The system automatically returns to the float mode when this time period expires. A
step-by-step procedure is provided next.
