User Instructions Section 5877
Spec. No. 582140000 (Models 802NLDB, 802NLEB and 802NL-B) Issue AQ, January 15, 2013
Chapter 3. System Operating Procedures Page 3-5
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MCA Controls and Indicators
Control / Indicator
Description
FUNCTION SELECT UP
FUNCTION SELECT DOWN
(Arrow Pushbuttons)
Moves up and down, respectively, through the list of available entries in the
currently displayed menu.
FUNCTION SET
ENTER/←/→
(Pushbutton)
Used to move to another menu, as determined by the currently displayed
entry. Also used to lock the displayed setting or value of the currently selected
menu entry, when in the adjustment or change setting mode.
Note: Pressing the ALARM CUTOFF pushbutton and the FUNCTION SET
ENTER pushbutton simultaneously, allows the User to enter the
adjustment or change setting mode, to change the value or setting of
the currently selected menu entry, if available.
FUNCTION SET YES (+) (i)
FUNCTION SET NO (-)
(Pushbuttons)
Used to increase or decrease the value of the currently selected menu entry
when in the adjustment or change setting mode.
Note: Pressing the FUNCTION SET YES (+) and NO (-) pushbuttons
simultaneously moves the user to the "Initial Message" display
(beginning).
Note: When in the adjustment or change setting mode, depressing the
FUNCTION SET YES (+) pushbutton after the "ARE YOU SURE?"
prompt accepts the new value or setting, depressing the FUNCTION
SET NO (-) pushbutton after the "ARE YOU SURE?" prompt cancels
the adjustment or change setting mode without making any changes.
Note: You can view additional information when the MCA displays the "i"
symbol by pressing this key.
ALARM CUTOFF
(Pushbutton)
Silences the audible alarm. Any new alarms will reactivate the audible alarm.
Note: Pressing the ALARM CUTOFF pushbutton and the FUNCTION SET
ENTER pushbutton simultaneously, allows the user to enter the
adjustment or change setting mode, to change the value or setting of
the currently selected menu entry, if available.
ALARM CUTOFF
(Indicator)
Illuminates yellow when the MCA audible alarm has been silenced using the
ALARM CUTOFF Pushbutton.
