Power Data Sheet PD588705000
Spec. No. 588705000 (Model PSS4850-23GV) Issue AP, September 12, 2013
Page 5 of 42
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
MAIN COMPONENTS ILLUSTRATIONS
Rectifier Module
P/N 1R483200,
P/N 1R483200E, or
P/N 1R483500E
(List 1, 3, 11, 21, 22,
31, 32, 51, 52, 53)
Module
Mounting Shelf
(List
1, 3, 11, 21, 22
,
31, 32, 40, 41, 42,
51, 52, 53)
(List 1 shown)
ACU+ Controller
P/N 1M820DNA
Module
Mounting Shelf
(List 61, 62, 63)
(List 61 shown)
Rectifier Module
P/N 1R483200,
P/N 1R483200E, or
P/N 1R483500E
Home
ACU+ IB2 Interface
Board
Converter Module
P/N 1C400483500E
(List 40, 41, 42)
