List 11, 22, 53, and 63 Module Mounting Shelf (208/240VAC Single Phase Input)
Refer to Table 4 for recommended wire size and Figure 5 or Figure 6 for terminal location.
LIST 11, 22, 53, AND 63 AC INPUT (Line Cords)
Line Cords for Individual Rectifier Module AC Input Branch Circuits are Factory Connected
(One AC Input Branch Circuit per Rectifier Module,
Five [List 63] or Six [List 11, 22, 53] AC Input Branch Circuits per Shelf)
Operating
Ambient
Temperature
Recm
Branch
Circuit
Protection
1, 2
30°C
25 Amperes
40°C
3
1
The AC input branch circuit protective device should be of the time-delay or high inrush type.
2
Recommendations based on Nominal Line Full Load Input Current of 18 Amperes.
3
Line cord option can only be used up to 40°C ambient.
Table 4
Recommended AC Input Branch Circuit Protection and Wire Size - List 11, 22, 53, and 63
