Power Data Sheet PD588705000
Spec. No. 588705000 (Model PSS4850-23GV) Issue AP, September 12, 2013
Page 23 of 42
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Figure 4
List 52 and 62 AC Input and Frame Ground Connections (Three-Phase Input) (Terminal Blocks)
Hole for 1"
Conduit Fitting
(AC Input)
Hole for 1"
Conduit Fittin
g
(AC Input)
Rear View
(List 52 shown)
Rear View
(List 52 shown)
Rectifier Module
Mounting Slots
(front view)
Rect.
1
Rect.
2
Rect.
3
Rect.
4
Rect.
5
Rect.
6
CONNECTIONS WITHIN THE SHELF
TB1, Terminal TB2, Terminal
Mounting
Position
1 (ØA) 2 (ØB) 3 (ØC) 1 (ØA) 2 (ØB) 3 (ØC)
L1 L2
L1 L2
L1 L2
L1 L2
L1
L2
Rect 6
Rect 5
Rect 4
Rect 3
Rect 2
Rect 1
L1 L2
List 52 only
(ØA)
TB2 TB1
(ØB)
(ØC)
(ØA)
(ØB)
(ØC)
AC IN Feed 2
Rectifier Modules
#4-#6 (List 52)
#4-#5 (List 62)
AC IN Feed 1
Rectifier Modules
#1-#3 (List 52, 62)
FRAME GROUND CONNECTION
ONE 10-32 X 3/4" STUD
AND HARDWARE, PER SIDE.
Recommended torque: 23 in-lbs.
F
RAME GROUND CONNECTION
ONE 10-32 X 3/4" STUD
AND HARDWARE, PER SIDE.
Recommended torque: 23 in-lbs.
AC IN: 208-240VAC, 50/60Hz, THREE PHASE
Wire Size Capacity: 6-14 AWG.
Recommended Torque: 6 AWG, 45 in-lbs.
8-14 AWG, 35 in-lbs.
