PD588705000 Power Data Sheet
Issue AP, September 12, 2013 Spec. No. 588705000 (Model PSS4850-23GV)
Page 2 of 42
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
General Specifications
See detailed specifications starting on page 34.
Family: NetSure™
Shelf Spec. No.: 588705000
Shelf Model: PSS4850-23GV
Shelf Input Ratings: List 1, 11, 21, 22, 31, 51, 53, 61, 63: 208/240VAC, 50/60Hz,
1-Phase, 17.3A/15A.
List 3, 32, 52, 62: 208/240VAC, 50/60Hz, 3-Phase, 29.3A/25.5A.
List 40, 41: 336VDC to 400VDC, 11A.
List 42: 336VDC to 400VDC, 33A.
Shelf Output Ratings: List 1, 3, 11, 21, 22, 31, 32, 40, 41, 42, 51, 52, 53: -48VDC, 437A,
21000W (maximum).
List 61, 62, 63: -48VDC, 364A, 17500W (maximum).
Rectifier Input Voltage: Nominal 208/240 volts AC, single phase, 50/60 Hz, with an operating
range of 176 to 264 volts. Acceptable input frequency range is 45 to
65 Hz.
Rectifier Output Voltage: -48 Volts DC, nominal.
Rectifier Output Capacity:
R48-3200 or R48-3200E: 55.2A @ -58.0VDC to 66.6A @ -48.0VDC, 3200 Watts (maximum).
R48-3500E: 60.3A @ -58.0VDC to 72.9A @ -48.0VDC, 3500 Watts (maximum).
Converter Input Voltage: 400 Volts DC, with an operating range of 336 to 400 volts.
Converter Output Voltage: -48 Volts DC, nominal.
Converter Output Capacity: 60.3A @ -58.0VDC to 72.9A @ -48.0VDC, 3500 Watts (maximum).
Agency Approval: UL 60950 Recognized; CAN/CSA 22.2, No. 60950-00
Framework Type: For Mounting in a 23 Inch Wide Relay Rack
Mounting Width: 23 Inch (Relay Rack Mounting)
Mounting Depth: List 1, 3, 11, 21, 22, 31, 32, 40, 41, 42: 17.50 Inches
List 51, 52, 53, 61, 62, 63: 18.75 Inches
Mounting Height: 5.25 Inches (3U)
Front Projection: List 1, 3, 11: Adjustable (flush, 1”, 2”, 3”, 4”, 5”, or 6”).
List 21, 22, 31, 32, 40, 41, 42: Fixed at 9”.
List 51, 52, 53, 61, 62, 63: Fixed at 6”.
Access: Front and Rear for Installation and Maintenance,
Front for Operation
Control: Microprocessor
Color: Bright Zinc Plating, Body
Textured Gray, Faceplates
Environment: -40°C to +65°C (-40°F to +149°F)
