PD588705000 Power Data Sheet
Issue AP, September 12, 2013 Spec. No. 588705000 (Model PSS4850-23GV)
Page 14 of 42
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
♦ Also provided is the IB2 ACU+ interface board which provides eight (8) programmable form-C
relay outputs, eight (8) programmable binary inputs, and two (2) temperature inputs.
Restrictions
Line cord option can only be used up to 40°C ambient.
Relay rack mounting angles fixed at 6” front projection.
Ordering Notes
1) Order rectifier modules as required per P/N 1R483200, P/N 1R483200E, or P/N 1R483500E.
2) Order a module mounting position blank cover panel, P/N 21140440, for each empty module mounting
position in the system, as desired.
3) Order one (1) ACU+ controller, P/N 1M820DNA.
4) Refer also to “ACCESSORY DESCRIPTIONS”.
