Instruction Manual

Instruction Manual Supplement
D104019X012
DVC6200p
November 2014
9
DO Module
Slot 3 Assignment
Module Module Name Input Bytes Output Bytes
18 DO_SP 0 2
19 DO_SP_RDBK 2 2
20 DO_SP_CKBK 3 2
21 DO_SP_RDBK_CKBK 5 2
22 DO_RIN_ROUT 2 2
23 DO_RIN_ROUT_CKBK 5 2
24 DO_SP_RDBK_RIN_ROUT_CKBK 7 4
Module 18
DO_SP
Module Definition DO_SP
Input data length 0
Output data length 2
Parameter data length 0
Identifiers 0xA1
Module 19
DO_SP_RDBK
Module Definition DO_SP_RDBK
Input data length 2
Output data length 2
Parameter data length 0
Identifiers 0xC1, 0x81, 0x81, 0x83
Module 20
DO_SP_CKBK
Module Definition DO_SP_CKBK
Input data length 3
Output data length 2
Parameter data length 0
Identifiers 0xC1, 0x81, 0x82, 0x92
Module 21
DO_SP_RDBK_CKBK
Module Definition DO_SP_RDBK_CKBK
Input data length 5
Output data length 2
Parameter data length 0
Identifiers 0xC1, 0x81, 0x84, 0x93
Module 22
DO_RIN_OUT
Module Definition DO_RIN_ROUT
Input data length 2
Output data length 2
Parameter data length 0
Identifiers 0xC1, 0x81, 0x81, 0x8C
Module 23
DO_RIN_ROUT_CKBK
Module Definition DO_RIN_ROUT_CKBK
Input data length 5
Output data length 2
Parameter data length 0
Identifiers 0xC1, 0x81, 0x84, 0x9C
Module 24
DO_SP_RDBK_ROUT_CKBK
Module Definition DO_SP_RDBK_RIN_ROUT_CKBK
Input data length 7
Output data length 4
Parameter data length 0
Identifiers 0xC1, 0x83, 0x86, 0x9F
