AI Module
Slot 2 Assignment
Module Module Name Input Bytes Output Bytes
16 AI_OUT(S) 5 0
17 AI_OUT(L) 5 0
Module 16
AI_OUT(S)
Module Definition AI_OUTS(S)
Input data length 5
Output data length 0
Parameter data length 0
Identifiers 0x94
Module 17
AI_OUT(L)
Module Definition AI_OUTS(L)
Input data length 5
Output data length 0
Parameter data length 0
Identifiers 0x42, 0x84, 0x5
