Module 12
AO_RIN_ROUT_CKBK(S)
Module Definition AO_RIN_ROUT_CKBK(S)
Input data length 8
Output data length 5
Parameter data length 0
Identifiers 0x97, 0xA4
Module 13
AO_RIN_ROUT_CKBK(L)
Module Definition AO_RIN_ROUT_CKBK(L)
Input data length 8
Output data length 5
Parameter data length 0
Identifiers
0xC5, 0x84, 0x87, 0x8, 0x5, 0x8, 0x5,
0xA
AO_RIN_ROUT_CKBK(S)
AO_RIN_ROUT_CKBK(L)
RCAS_OUT
CHECKBACK
RCAS_IN
Readback cascade output, checkback,
remote cascade input
Input (master view)
Initial Address 0
1 RCAS_OUT -
2 floating-point number
3
4 RCAS_OUT - status
5
CHECKBACK
6
7
Output (master view)
Initial Address 0
1 RCAS_IN -
2 floating-point number
3
4 RCAS_IN - status
