AO Module
Slot 1 Assignment
Module Module Name Input Bytes Output Bytes
1 EMPTY_MODULE 0 0
2 AO_SP(S) 0 5
3 AO_SP(L) 0 5
4 AO_SP_RDBK_POSD(S) 7 5
5 AO_SP_RDBK_POSD(L) 7 5
6 AO_SP_CKBK(S) 3 5
7 AO_SP_CKBK(L) 3 5
8 AO_SP_RDBK_POSD_CKBK(S) 10 5
9 AO_SP_RDBK_POSD_CKBK(L) 10 5
10 AO_RIN_ROUT(S) 5 5
11 AO_RIN_ROUT(L) 5 5
12 AO_RIN_ROUT_CKBK(S) 8 5
13 AO_RIN_ROUT_CKBK(L) 8 5
14 AO_SP_RDBK_RIN_ROUT_POSD(S) 15 10
15 AO_SP_RDBK_RIN_ROUT_POSD(L) 15 10
Module 2
AO_SP(S)
Module Definition AO_SP(S)
Input data length 0
Output data length 5
Parameter data length 0
Identifiers 0xA4
Module 3
AO_SP(L)
Module Definition AO_SP(L)
Input data length 0
Output data length 5
Parameter data length 0
Identifiers 0x82, 0x84, 0x8, 0x5
AO_SP(S)
AO_SP(L)
SP Setpoint
Output (master view)
Initial Address 0
1 SP -
2 floating-point number
3
4 SP - status
