Installation Manual

BOTTOM
PLATE
2/3” [16.9] dia. (6x)
6.625” [168.3]
7.125” [181.0]
3.125”
[79.4]
1.281”
[32.5]
2.563”
[65.1]
Emerson Network Power Contact information
Surge Protection
100 Emerson Parkway
Binghamton, NY 13905
T: [phone]
T: [phone]
F: [phone]
E: [e-mail]
IO-50152 3/15 Rev. 2 Printed in USA
www.EmersonNetworkPower.com/Surge
While every precaution has been taken to ensure accuracy and completeness herein, Emerson Network Power Surge Protection assumes no responsibility, and disclaims all liability, for damages
resulting from use of this information or for any errors or omissions. Specications are subject to change without notice.
Emerson Network Power, the Emerson Network Power logo and Edco are trademarks
and service marks of Emerson Electric Co. ©2014 Emerson Electric Co.
Mounting
Pin Out
Line In 1, 2
Neutral In 11, 12
Ground 3, 4, 9, 10
Line Out 5
Neutral Out 7
Relay NC 8
Relay Com 6
SHA-1250 Insertion Loss
