6.4.2.7 Process Data Image
Organisation of the user data communicated via brickBUS:
Out-Userdata from Master to Slave
total: 0 Bytes
In-Userdata to Master from Slave
total: 16 Bytes
Byte
Function
rC Assign...
Byte
Function
rC Assign...
all not used
0,1
Analog Input 1
1..698 Dig. ≡ 0..5 V
... + eB_W0, 0, ...
2, 3
Analog Input 2
1..698 Dig. ≡ 0..5 V
... + eB_W1, 0, ...
4, 5
Analog Input 3
1..698 Dig. ≡ 0..5 V
... + eB_W2, 0, ...
6, 7
Analog Input 4
1..698 Dig. ≡ 0..5 V
... + eB_W3, 0, ...
8, 9
Analog Input 5
1..698 Dig. ≡ 0..5 V
... + eB_W4, 0, ...
10, 11
Analog Input 6
1..698 Dig. ≡ 0..5 V
... + eB_W5, 0, ...
12, 13
Analog Input 7
... + eB_W6, 0, ...
14, 15
Analog Input 8
... + eB_W7, 0, ...
Analog Input
-
-
-
-
-
-
AIV9
AIV8
Bit 15
Bit 8
AIV7
AIV6
AIV5
AIV4
AIV3
AIV2
AIV1
AIV0
Bit 7
Bit 0
Bit 9-0 ......................................... AIV<9:0>: Analog Input Value (Little Endian)
11 1111 1111 = Analog Input Value: 1023
…
00 0000 0000 = Analog Input Value: 0
6.4.2.8 Programming Note
In Addition to the notes in chapter 4, please regard the following:
 A calibration has to be done in the applications software.
 A Conversion from °C into °F has to be done in the application software
 After every communication all inputs will be updated
 To stabilize the messurement results, they should be filtered in the application
