6.4.2.6 Technical Data
Note: For further global specification refer to chapter 4.
Inputs:
Number of moti inputs .............. 6
Connection technology ......... 2/3-wire (supports sensor power supply)
Type ....................................... voltage
Input range ............................ nom. 0...5V (full ADC approx. 0...7,3V , max. 15V)
Input resistance .................... approx. 50kOhm
Resolution .............................. 10 Bit, 0.1% (related on measure range)
Linearity ................................. 0.2% (related on measure range)
Accuracy ................................ 0.5% (related on measure range)
Filter....................................... hardware, 1
st
order, f
cut off
= approx. 100Hz
Number of LDR inputs ............... 2
Connection technology ......... 2-wire (supports shield)
Type ....................................... LDR07
Measure current .................... approx. 0.6 mA
Resolution .............................. 10 Bit, 0.1% (related on measure range)
Linearity ................................. 0.2% (related on measure range)
Accuracy ................................ 0.5% (related on measure range)
Filter....................................... hardware, 1
st
order, f
cut off
= approx. 100Hz
Others:
Bus power consumption ........... sensor supply@24V, <10mA@3.3V
Isolation buses to I/O ................ none (important details: consider to chapter 4)
Status indication ....................... LEDs for each digital input, output and for the module status
Mechanics:
Terminals (others) ..................... 2x12, cage clamp Wago250
Connection (others) .................. usable with one litz wire from 0.2 – 0.5 mm²
Dimensions .............................. 44 x 72 x 20 mm
Weight ...................................... approx. 30g
Options:
Plug-in terminals ....................... optional available
