Installation
Page 16
Please take the time to familiarise yourself with the system elements and
their connections prior to attempting installation.
Figure 4 Typical installation configuration without antenna splitter
Power in
Switch
NMEA 2000
Chartplotter
VHF antenna
USB
NMEA 0183 device
GNSS antenna
(Optional)
AIS Class B
transceiver
