Figure 1. Location of internal antennas
Figure 2. Location of Wireless WIC external antenna
Wireless WIC internal
antenna
Internal antenna for
connection to the EA_LAN
Electronic housing of
the A3 ALPHA meter
(Present only when serving
as an EA_Gatekeeper)
Wireless WIC external antenna
