Appendix A Switch Configuration
Man_905UD_2.0.doc Page 55
•
Configuration mde will automatically
exit as Transparent Mode
•
Set Operating Mode to Transparent
Repeater and press button until RX
LED lights.
Unit No. 2 Configuration
• Set the System Address
•
Press the red button for approx. 3
seconds - until the RX LED comes on.
•
Configuration mde will automatically
exit as Transparent Mode
•
Set serial data rate to 9600 bits/sec
and press button until RX LED lights.
•
Set radio data rate to 9600 bits/sec
and press button until RX LED lights.
•
Set the character type to 7,1,2,E,
disabled control, and press button
until RX LED lights.
Note that as RS485 is used, the
CTS/RTS control is disabled.
