TECHNICAL SPECIFICATIONS
Display Modes
Your Elo touchmonitor is compatible with the following standard
video modes:
Item Resolution Type H. Scan(KHz) V. Scan(Hz) Pol.
1 640 x 350 VGA 70Hz 31.47 28.322
2 720 x 400 VGA 70Hz 31.47 28.322
3 640 x 480 VGA 60Hz 31.47 25.175
4 640 x 480 MAC 66Hz 35 32.24 -/-
5 640 x 480 VESA 72Hz 37.86 31.5 -/-
6 640 x 480 VESA 75Hz 37.5 31.5 -/-
7 800 x 600 VESA 56Hz 35.16 36 +/+
8 800 x 600 VESA 60Hz 37.88 40 +/+
9 800 x 600 VESA 75Hz 46.88 49.5 +/+
10 800 x 600 VESA 72Hz 48.08 50 +/+
11 832 x 624 MAC 75Hz 49.72 57.283 -/-
12 1024 x 768 VESA 60Hz 48.36 65 -/-
13 1024 x 768 SUN 65Hz 52.45 70.49 -/-
14 1024 x 768 VESA 70Hz 56.48 75 -/-
15 1024 x 768 VESA 75Hz 60.02 78.75 +/+
16 1280 x 1024 SXGA 60Hz 64 108 +/+
17 1280 x 1024 SXGA 75Hz 80 135 +/+
18 1152 x 864 SXGA 75Hz 67.5 108 +/+
19 1280 x 960 SXGA 60Hz 60 108 +/+
