User guide

OSD Control Options
Brightness
• Background Luminance of the LCD panel is adjusted.
Contrast
• Adjusts the contrast or the values of color gain (RED, GREEN or BLUE).
V-Position
• Moves the screen up or down.
H-Position
• Moves the screen left or right.
Recall Defaults
• All data copy from factory shipment data.
Color Temperature
• Press or to select 9300, 6500, 5500, 7500 and user. Only when selecting user
you can malce adjustments to the R/G/B content.
Volume
• To increase or decrease the sound level.
Sharpness
• The sharpness can be adjustable.
Phase
• Adjusts the phase of the dot clock.
Clock
• Adjusts the ratio of dividing frequency of the dot clock.
OSD Position
• Allows the OSD indication position to be selected.
OSD Timeout
• Adjust time for OSD to disappear.
Auto Adjust
• Clock system auto adjustment (under 5 seconds).
Language
• Select the language used for the OSD menu from among English, France, Deutsch,
Spanish and Japanese.
Input Select
• Selection of the input signal: DSUB analog or DVI digital.
3-30 Elo Touchmonitor User Guide
