Low Threshold Shower 60″ x 32″

Ella Freedom - Left or Right Seat

www.ellasbubbles.com Page 1 11/13

Model # 6032 SH IS 3P 4.0 L-WH FRDM

6032 SH IS 3P 4.0 R-WH FRDM

6032 SH IS 3P 4.0 L-BN FRDM

6032 SH IS 3P 4.0 R-BN FRDM

6032 SH IS 3P 4.0 L-B FRDM

6032 SH IS 3P 4.0 R-B FRDM

Panels:

Shower Base .............................. 33″ W x 60″ L x 28″ H

Side Wall Panel Left .................. 33″ W x 30″ L x 49″ H

Side Wall Panel Right ................ 33″ W x 30″ L x 49″ H

Features:

• Premium marine grade gel-coat, three piece shower

with 6″ classic tile pattern design and diamond accent

• Wood reinforced walls for placing grab bars

and seats anywhere (not dependent on stud locations)

• Easy shower wall assembly pin-lock system allowing

front side installation

• Precision t wall panel seams (match into grout pattern)

• Grip-Sure

™

oor texture

• Self supporting, pre-leveled shower base

(no mudset required)

• Shower door friendly (squared corners allow

door installations)

• Ships pre-assembled, heavy duty crating protects

product in transit

Accessories:

• Three (3) 16″ Polished Chrome Finish Curved

Grab Bars

• One (1) 2-in-1 Grab Bar for Shower Valve

• 2″ Chrome strainer brass drain with friction seal

Codes:

IPC, UPC, ANSI Z 124.2, NAHB, HUD, FHA

Warranty:

30 Year Limited Lifetime Warranty (on shower panels)*

*For more information please visit www.ellasbubbles.com

Outside Dimensions: 33″ W x 60″ L x 77″ H

Seat Dimensions: 22″ W x 18.5″ L x 21″ H

Shipping Dimensions: 48″ W x 63″ L x 40″ H

Shipping Weight: 300 lbs.

Net Weight: 290 lbs.

Threshold Height: 4″

Package Options:

• White (W), Bone (BN) or Biscuit (B) Shower Panels

• Left or Right Seat

• Standard (no xtures), Standard Plus 24, Standard Plus 36

or Freedom

• Prestige (premium xtures)

• Flange Trim Molding Kit

• Multi-Piece Window Trim Kit

2″ Chrome Strainer

Brass Drain with Friction Seal

Polished Chrome Curved Grab

Bars with Covered Flange

Polished Chrome 2-in1

Shower Valve Grab Bar

Ella Freedom Accessories (below):

The Perfect Fall Prevention System

cessories

MAKING LIFE EASY, SAFE AND BEAUTIFUL

Grab

Summary of content (3 pages)

PAGE 1
Low Threshold Shower 60″ x 32″ Ella Freedom - Left or Right Seat Model # 6032 SH IS 3P 4.0 L-WH FRDM 6032 SH IS 3P 4.0 R-WH FRDM 6032 SH IS 3P 4.0 L-BN FRDM 6032 SH IS 3P 4.0 R-BN FRDM 6032 SH IS 3P 4.0 L-B FRDM 6032 SH IS 3P 4.0 R-B FRDM Ella Freedom Accessories (below): Grabcessories MAKING LIFE EASY, SAFE AND BEAUTIFUL The Perfect Fall Prevention System Outside Dimensions: 33″ W x 60″ L x 77″ H Seat Dimensions: 22″ W x 18.
PAGE 2
Low Threshold Shower 60″ x 32″ 6032 SH IS 3P 4.0 - Left or Right Seat *Left Seat Shown Disclaimer: In an effort to continually improve our product, specifications and configurations are subject to change without notice. Before ordering or installing, consider future access to essential equipment. Due to the nature of the materials, dimensions may vary ± 1/2″. www.ellasbubbles.
PAGE 3
Low Threshold Shower 60″ x 32″ Ella Standard Features ADAPTABILITY STRENGTH Customized Accessory Placement Wood & Steel Reinforced Walls Fiberglass resin structural substrate cures to a seamless strong encasement. All panels are backed with 3/8" wood, accessories can be installed anywhere. Exact placement of accessories for any size person. Custom Seat Placement SHOWER DOOR FRIENDLY Premium Marine-grade Gel-coat fiberglass surface for beautiful. long-lasting shower surface.
