12
7-1/2"
(191mm)
7-1/2"
(191mm)
17-1/2"
(445mm)
20"
(508mm)
15"
(381mm)
17-1/2"
(445mm)
31-1/4"
(794mm)
11-1/2"
(292mm)
16"
(406mm)
Model ELUH3119L Illustrated
7-1/2"
(191mm)
7-1/2"
(191mm)
17-1/2"
(445mm)
20"
(508mm)
15"
(381mm)
17-1/2"
(445mm)
31-1/4"
(794mm)
11-1/2"
(292mm)
16"
(406mm)
Model ELUH3119R Illustrated
10"
(254mm)
10"
(254mm)
Model ELUH311910L Illustrated
Model ELUH311910R Illustrated
Harmony
®
Undermount Double Bowl Sink
Model ELUH3119 Series
®
SP E C I FI C ATIO N S
Elkay
2222 Camden Court
Oak Brook, IL 60523
elkayusa.com
Printed in U.S.A.
©2011 Elkay
1-123J(Rev. 03/11)
Inside Inside
Minimum
Model
Overall Left Bowl Right Bowl
Cutout in Cabinet
Number L W L
W D L W D
ELUH3119L 31
1
/4 20 11
1
/2 15 7
1
/2 16 17
1
/2 7
1
/2
(794mm) (508mm) (292mm) (381mm) (191mm) (406mm) (445mm) (191mm)
36
(914mm)
ELUH3119R 31
1
/4 20 16 17
1
/2 7
1
/2 11
1
/2 15 7
1
/2
(794mm) (508mm) (406mm) (445mm) (191mm) (292mm) (381mm) (191mm)
36
(914mm)
ELUH311910L 31
1
/4 20 11
1
/2 15 7
1
/2 16 17
1
/2 10
(794mm) (508mm) (292mm) (381mm) (191mm) (406mm) (445mm) (254mm)
36
(914mm)
ELUH311910R 31
1
/4 20 16 17
1
/2 10 11
1
/2 15 7
1
/2
(794mm) (508mm) (406mm) (445mm) (254mm) (292mm) (381mm) (191mm)
36
(914mm)
SINK DIMENSIONS*
See
Template**
Model ELUH3119L and ELUH311910L Illustrated Model ELUH3119R and ELUH311910R Illustrated
ELUH3119L_ _ _ 31
1
/4 20 11
1
/2 15 7
1
/2 16 17
1
/2 7
1
/2
(794mm) (508mm) (292mm) (381mm) (191mm) (406mm) (445mm) (191mm)
36
(914mm)
ELUH3119R_ _ _ 31
1
/4 20 16 17
1
/2 7
1
/2 11
1
/2 15 7
1
/2
(794mm) (508mm) (406mm) (445mm) (191mm) (292mm) (381mm) (191mm)
36
(914mm)
ELUH311910L_ _ _ 31
1
/4 20 11
1
/2 15 7
1
/2 16 17
1
/2 10
(794mm) (508mm) (292mm) (381mm) (191mm) (406mm) (445mm) (254mm)
36
(914mm)
ELUH311910R_ _ _ 31
1
/4 20 16 17
1
/2 10 11
1
/2 15 7
1
/2
(794mm) (508mm) (406mm) (445mm) (254mm) (292mm) (381mm) (191mm)
36
(914mm)
*Length is left to right. Width is front to back.
(Statement option)
(Statement option)
(Statement option)
(Statement option)
Countertop Size
SINKS ARE
MADE IN THE USA
**Template #74180232 is packed with every sink.
