Datasheet

M2F2G64CB88B7N / M2F4G64CB8HB5N
M2F2G64CB88BHN / M2F4G64CB8HB9N
2GB: 256M x 64 / 4GB: 512M x 64PC3-8500 / PC3-10600/PC-12800
Unbuffered DDR3 SDRAM DIMM
REV 1.1 11
10/2010
© NANYA TECHNOLOGY CORPORATION
NANYA reserves the right to change products and specifications without notice.
Operating, Standby, and Refresh Currents
T
CASE
= 0 °C ~ 85 °C; V
DDQ
= V
DD
= 1.5V ± 0.075V [2GB – 1 Rank, 256Mx8 DDR3 SDRAMs]
Symbol
Parameter/Condition
PC3-8500
PC3-10600
PC3-12800
Unit
(-BE)
(-CG)
(-DI)
IDD0
Operating One Bank Active-Precharge Current
577
579
609
mA
IDD1
Operating One Bank Active-Read-Precharge Current
725
750
790
mA
IDD2P0
Precharge Power-Down Current Slow Exit
33
48
51
mA
IDD2P1
Precharge Power-Down Current Fast Exit
104
132
143
mA
IDD2Q
Precharge Quiet Standby Current
167
204
185
mA
IDD2N
Precharge Standby Current
182
220
243
mA
IDD3P
Active Power-Down Current
114
144
158
mA
IDD3N
Active Standby Current
236
231
255
mA
IDD4R
Operating Burst Read Current
1011
1302
1510
mA
IDD4W
Operating Burst Write Current
1028
1239
1438
mA
IDD5B
Burst Refresh Current
1531
1507
1531
mA
IDD6
Self Refresh Current: Normal Temperature Range
83
56
56
mA
IDD7
Operating Bank Interleave Read Current
2590
2997
3062
mA
Operating, Standby, and Refresh Currents
T
CASE
= 0 °C ~ 85 °C; V
DDQ
= V
DD
= 1.5V ± 0.075V [4GB – 2 Ranks, 256Mx8 DDR3 SDRAMs]
Symbol
Parameter/Condition
PC3-8500
PC3-10600
PC3-12800
Unit
(-BE)
(-CG)
(-DI)
IDD0
Operating One Bank Active-Precharge Current
813
810
864
mA
IDD1
Operating One Bank Active-Read-Precharge Current
961
980
1045
mA
IDD2P0
Precharge Power-Down Current Slow Exit
66
95
102
mA
IDD2P1
Precharge Power-Down Current Fast Exit
209
264
285
mA
IDD2Q
Precharge Quiet Standby Current
333
408
370
mA
IDD2N
Precharge Standby Current
364
440
486
mA
IDD3P
Active Power-Down Current
228
289
317
mA
IDD3N
Active Standby Current
472
461
510
mA
IDD4R
Operating Burst Read Current
1247
1533
1765
mA
IDD4W
Operating Burst Write Current
1264
1470
1693
mA
IDD5B
Burst Refresh Current
1767
1737
1786
mA
IDD6
Self Refresh Current: Normal Temperature Range
167
113
113
mA
IDD7
Operating Bank Interleave Read Current
2826
3228
3318
mA
