Manual

Chapter 1
2
VX900-I2 USER MANUAL
CPU
Specifications
Form Factor
• Mini-ITX Size, 170mm x 170mm
• VIA
®
VX900 ChipsetChipset
• Single-channel DDR3 SO-DIMM memory architecture
• 1 x 204-pin DDR3 SO-DIMM sockets support up to 8 GB
• Supports DDR3 1066 MHz DDR3 SDRAM
Memory
• 1 x PCIEX8 slot
• 1 x Mini PCIE slot
• Supported by VIA
®
VX900 Express Chipset
- 2 x Serial ATA 3Gb/s devices
- 1 x Half-Slim SATA connector
Expansion Slots
Storage
• 1 x PS/2 keyboard connector
• 1 x PS/2 mouse connector
• 1 x DVI-I port
• 1 x Display port
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x DC_IN jack
Rear Panel I/O
LAN • Realtek 8111E Gigabit Lan
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Onboard VIA
®
Eden X2 Dual Core U4200 1GHz/VIA
®
Nano Single
Core U3300 1.2GHz processor
• Supports FSB 800MHz
Note: Please go to ECS website for the latest Memory support list.
• 1 x 4-pin DC_IN header
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SATA_PWR connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 2 x Serial ATA 3Gb/s connectors
• 1 x Half-Slim SATA connector
• 3 x COM headers
• 1 x LDC header
• 1 x VGA header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Mono Speaker connector
• 1 x Parallel port header (LPT)
• 1 x CLR_CMOS header
Internal I/O
Connectors &
Headers
• Realtek ALC269
- 2+2 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
