Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices.
ECP Mode DMA Channel (DMA3)
Use this item to assign a DMA channel to the parallel port.
USB Functions (Enabled)
Use this item to enable or disable the USB function.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
SATA Configuration IDE
ON Chip SATA 6Gb/s Controller IDE
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/ IRQ4
Serial Port2 Address 2F8/ IRQ3
Serial Port3 Address Enabled
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
Help Item
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard audio device.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
Onboard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN.
Serial Port1/Port2/Port3 Address (3F8/IRQ4 / 2F8/IRQ3 / Enabled)
Use this item to enable or disable the onboard COM1/COM2/COM3 serial port, and
to assign a port address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can select Normal (Standard
Parallel Port), ECP (Extended Capabilities Port), or EPP (Enhanced Parallel Port).
Press <Esc> to return to the main menu setting page.
SATA Configuration (IDE)
Use this item to show the Serial ATA Configuration options: IDE, RAID.
F1:General Help
: Move F10: Save and Exit+/-/PU/PD: ValueEnter : Select
F9: Load Default Settings
ESC: Exit
ON Chip SATA 6Gb/s Controlle (IDE)
This item allows you to enable or disable onchip SATA 6Gb/s controller.
Parallel Port IRQ (IRQ7)
Use this item to assign IRQ to the parallel port.
IDE
RAID
Options
