A960M-M4 USER MANUAL
1
Brief Introduction
CPU
Specifications
• NB: AMD 760G (RS780L)
SB: AMD SB710
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3
1866(OC)/1600/1333/1066 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot
• 1 x PCI Express x1 slot
• Supported by AMD SB710 Express Chipset
- 4 x Serial ATA 3Gb/s connectors
- Supports RAID 0, 1, 10
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x HDMI port (optional)
• 1 x D-sub (VGA) port
• 1 x Parallel port (LPT1)
• 1 x Audio port (Line in, microphone and Line out)
Rear Panel I/O
• supports socket AM3/AM3+ for AMD FX
TM
/Phenom
TM
II/Athlon
TM
II/Sempron
TM
100 series processors
• Supports CPU up to 95W TDP (Overspec Supports to 125W)
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x Clear CMOS jumper
• 1 x Front panel USB power select jumper
• 1 x Rear USB/PS2 power select jumper
Internal I/O
Connectors &
Headers
• Realtek ALC 662 6 channel High Definition audio CODEC
- Compliant with HD audio specification
Audio
LAN
• Realtek RTL8111E Gigabit LAN
• Realtek RTL8105E 10/100 LAN (optional)
Note: Please go to ECS website for the latest memory support list.
