Personal Inventory This DeskNote computer system is designed for years of productive and pleasurable computing. Use this section to keep notes about details of your purchase. Update this section when you add new options.
Chapter 1 Introduction User's Info: There are more and more people spending large amounts of time in front of computer monitors now that scientists from many fields including anatomy, psychology, and occupational safety are involved in the study of ergonomically sound work environments. A few tips to help you work effectively without a lot of physical discomfort: • Purchase a chair with armrests and good back support. Don't slouch when sitting; keep your back straight.
Welcome to the DeskNote Computer Congratulations on your purchase of the DeskNote computer. Your DeskNote features the latest advances in portable computing technology. The DeskNote is designed for those who need the full power of a desktop PC with a modular design to provide maximum expandability without compromising portability. The high-performance CPU and enhanced IDE hard drive provide you with extra processing power for handling complex graphics and running large programs.
Accessories and Optional Devices TV-Out cable External battery (optional) Getting to Know Your Computer Opening the LCD Panel At the front of the DeskNote you will find a retaining latch on the display panel, which locks the display in closed position when the DeskNote is not in use. 1. Slide the display panel latch and then raise the LCD screen. 2. At any time you can tilt the display toward or away from you to a comfortable viewing position. CAUTION: To avoid damage to the display panel: 1.
Each of these features is briefly described below. 1. LCD Cover Release Latch - Allows you to open the display panel and reveal the LCD screen and the keyboard. 2. LCD Screen - Your DeskNote computer is equipped with a replaceable color Liquid Crystal Display (LCD) screen that supports up to 1024 x 768 LCD resolution. 3. System Status Indicator Panel - The system status indicator panel keeps you informed of the computer’s operating status.
HDD - Indicates that the computer is accessing the hard disk drive. NumLock - Indicates that the keyboard is in Num Lock mode. Caps Lock - Indicates when the keyboard is in Caps Lock mode. In this mode, the keyboard produces uppercase text when you press a key. When you press the Caps Lock key again, the indicator goes off and the keyboard produces lowercase text. Scroll Lock - Indicates when the keyboard is in Scroll Lock mode.
The Right Side 1. The CD-ROM/DVD-ROM Drive - Your DeskNote comes with a swappable 24X (or higher) 5.25" IDE CD-ROM or 8X DVD-ROM drive. 2. Modem Port - You will able to connect your computer to your phone line through this port. CAUTION: Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment. To reduce the risk of fire use only No. 26 AWG or larger telecommunication line cord. 3.
The Left Side Power LED Indicators These two LED indicators are separately programmed for the following functions: Suspend mode and Power On. 1. Suspend mode - This indicator will lit when the DeskNote is in suspend mode. 2. Power On - This indicator will lit when the DeskNote is powered on. 3. Cooling Fan Vent - This fan prevents the DeskNote CPU and other internal components from becoming overheated. Keep this fan unobstructed to allow proper ventilation to the DeskNote's internal components. 4.
Can be used to connect up 63 external devices, also supports isochronous data -- delivering data at a guaranteed rate. This makes it ideal for devices that need to transfer high levels of data in real-time, such as video devices. Also supports both Plug-and-Play and hot plugging, and also provides power to peripheral devices. The Rear Side 1. Headphone Jack - This is for headphone output that supports SPDIF output 5.1 channel.
7. LAN Port - This port provides a standard RJ-45 connection with an existing network via a network cable. 8. Cooling Fan Vent - This fan prevents the DeskNote CPU and other internal components from becoming overheated. Keep this fan unobstructed to allow proper ventilation to the DeskNote's internal components. The Bottom 1. Expansion Compartment - This compartment will serve as an expansion to upgrade your DDR module. 2.
Preparing the DeskNote for Transport To prepare the computer for transport, you should first disconnect all peripherals. Make sure the computer is turned off before you do this. After disconnecting all peripherals, close the rear port covers to protect the connectors. The DeskNote hard disk head is self-parking. This means that the DeskNote can be directly turned off from the DOS prompt.
Chapter 2 Getting Started Connecting the AC Adapter A universal AC adapter or an optional UPS is provided to supply your computer with power. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country.
1. Plug the AC adapter’s connector into the connector on the rear side of the DeskNote. 2. Connect the power cord to the AC adapter and then to a wall outlet. CAUTION: The best kind of AC power source to connect your DeskNote to an external battery. Lacking this, use a power strip with a built-in surge protector. Do not use inferior extension cords as this may result in damage to your DeskNote. The DeskNote comes with its own AC adapter.
To turn the DeskNote off, save your work and close all open applications, click on Start, then Shut Down and select Shut down the computer and click "Yes" or press the power button for 4 seconds. About the ROM BIOS Your DeskNote computer is configured with a customized Basic Input/Output System (BIOS), which tests the computer and determines how the computer reacts to specific instructions that are part of programs.
Resetting the System After installing a software application package, you may be prompted to reset the system to load the changed operating environment. To reset the system, or “reboot,” press the [Ctrl] + [Alt] + [Delete] keys simultaneously. This is known as “warm boot.” This key combination acts as a “software” reset switch when you encounter hardware or software problems, which lock up the DeskNote.
Chapter 3 Using the DeskNote Computer The LCD Display The DeskNote computer comes with a Color LCD display panel that supports the following display options: Display Resolution Color Depth 15.0" SXGA TFT 1280 x 1024 32 bit 15.0" XGA TFT 1024 x 768 32 bit 14.1" XGA TFT 1024 x 768 32 bit All displays support up to 1024 x 768 x 64K color mode on an external CRT. The LCD screen display results can be adjusted by changing the LCD panel angle, and the display brightness.
[Fn] + [F12] This key combination toggles the display between the LCD display and an external CRT or TV simultaneously. LCD Care LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: When you are not using the computer, keep the LCD screen closed to protect it from dust. If you need to clean your LCD screen, use a soft tissue to gently wipe the LCD surface.
The QWERTY layout means the alphanumeric keys located on the keyboard are in the same position as those found on a standard typewriter. The function keys (F1-F12) on the top row of the keyboard serve different purposes and carry out different tasks depending on the application you are running.
The DeskNote’s Hot Key Controls Your DeskNote also contains controls, which are feature in blue color on the keys activated by pressing the [Fn] key (the key in the lower left corner of the keyboard beside the [Ctrl] key) in conjunction with the key for specific control function. To activate these keys, hold the [Fn] key and press the specific control function. Key Combinations Power button Definitions Press this button once to turn On your notebook.
The TouchPad Using the TouchPad The TouchPad is a pressure sensitive pointing device that provides all the features of a two-button mouse. 1. The TouchPad is easily accessible by moving either your left or right thumb off the space bar and on to the TouchPad. 2. Gently move your thumb across the pressure-sensitive TouchPad in the direction you want the cursor to move. 3. The TouchPad offers a method of making selections called double-tapping and this corresponds to double-clicking with a mouse.
4. Clicking the buttons below the TouchPad makes selections, drags objects, or performs a variety of other functions depending on the software. TouchPad Precautions The TouchPad is a pressure sensitive device. Please take note of the following precautions. Make sure the TouchPad does not come into contact with dirt, liquids or grease. Do not touch the TouchPad if your fingers are dirty. Do not rest heavy objects on the TouchPad or the TouchPad buttons.
1. Remove the two screws and set them in a safe place. Slide the grip into the direction away from you as shown in the illustration. 2. Use a screwdriver to lift up the HDD cover from the compartment. 3. Remove the two screws attached to the HDD drive. Lift up the HDD from its compartment.
4. Remove the new hard drive from its anti-static bag. You can use the same anti-static bag to store your old hard drive. 5. To install the new hard drive, align the tabs on the drive bracket with the slots on the bay and press it gently ease the drive into the bay. Slide the drive until it iengages with the system. 6. Slide the compartment cover into place. Be sure that the screw holes on the cover align completely with the screw holes in the case and secure the cover with the two screws.
Supports CD-DA, CD-ROM mode 1 and mode 2, Multi-Session Photo CD™, CD-I/Video CD (pcs.) Low power consumption 12.7mm height Precautions for Handling CD-ROM Discs Always hold the disc by the edges, avoid touching the surface. Use a clean, dry, cloth to remove dust, smudges, or fingerprints. Wipe from the center outward. Do not write or place objects on the surface of the disc. Store discs in a cool dry place not to damage the disc. Do not use benzene, thinners, or cleaners with detergent.
NOTE: Do not insert any foreign objects into the disc tray. If you experience difficulty when ejecting the CD disk tray, stretch a paper clip (or use a pin or a thin metal rod) and insert it into the emergency eject hole located on the right side of the front panel. The CD disk tray should eject immediately. This procedure can also be used to remove a CD from the drive when the DeskNote is powered off.
Connecting Peripheral Devices To expand your computing capabilities, you can add a variety of external devices to your computer. You may, for example, want to add a mouse, modem, or a printer. The computer is equipped with several interface ports, including an enhanced parallel (printer) port, a serial port, and 4 USB ports. These are provided as a means of connecting peripheral devices to the computer.
Power Saving Modes This section contains information on the DeskNote's power system, including the AC Adapter, the UPS system, recharging the UPS, and tips for conserving UPS power. The power system is comprised of two parts, the AC Adapter and the UPS system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer. The AC Adapter The AC Adapter’s primary function is to provide power to the DeskNote.
Chapter 4 Running BIOS Setup Introduction The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to reflect installed hardware or alter system performance. When the DeskNote is turned back on, the system is configured with the values stored in CMOS. Navigating through BIOS Setup The Setup program has been designed to make it as easy to use as possible.
Item Specific Help On the right side of the Setup screen is an area labeled Item Specific Help. This area will list navigation key shortcuts and information that is specific for the item that you are currently editing. The Menu Bar The top of the screen has a menu bar with the following selections: Standard CMOS Setup Set the time and date. Configure disk drives. Advanced CMOS Setup Configure basic system performance parameters. Peripheral Setup Configure I/O support for the DeskNote.
F2/F3 Set the color (8 colors) of the BIOS Setup screen. F10 Save and Exit. Enter Will select a sub menu or show a range of options for a field. Launching Submenus Note that a right pointer symbol ¾ appears to the left of certain fields. This pointer indicates that a submenu can be launched from this field. A submenu contains additional options for a field parameter. To call up a submenu, simply move the cursor to highlight the field and press the [Enter] key.
The Standard CMOS Setup When the Setup program is accessed, the following screen appears: Date/Time The current values for each category are displayed. Enter new values through the keyboard. Pri Master, Sec Master Select one of these hard disk drive icons to configure the hard disk drive named in the option.
The Advanced CMOS Setup When the Setup program is accessed, the following screen appears: CPU/DRAM Base Frequency Set this option to select the CPU/DRAM base frequency for your system. The settings are 100/100MHz or 100/133 MHz DRAM CAS# Latency Set the amount of time to access the memory. The settings are 2.
Quick Boot Set this option to Enabled to instruct AMIBIOS to boot quickly when the computer is powered on. The settings are Disabled or Enabled (default value). 1st Boot Device This option sets the type of device for the first boot drives that the AMIBIOS attempts to boot from after AMIBIOS POST completes. The settings are Disabled, HDD (default value), CD-ROM and USB FDD.
Password Check This option enables password checking every time the system boots or when you run AMIBIOS Setup. If Always is chosen, a user password prompt appears every time the computer is turned on. If Setup is chosen, the password prompt appears if AMIBIOS is executed. PCI IDE BusMaster Set this option to Enabled to specify that the IDE controller on the PCI bus has bus mastering capability. The settings are Disabled (default value) or Enabled.
The Peripheral Setup LCD TV Display Type This field allows you to choose the television display option when using the TV out port. The settings are PAL, NTSC (default value). TV PAL Display Type This field allows you to choose the television PAL system type. The settings are PAL (default value), PAL-M, PAL-N. IR Port Support This option specifies the IR port address for the IR Port.
The settings are Disabled, 6F8h (default value), 7F8h, 7E8h or 6E8h. IR Mode Select This option specifies the infrared transmission method. The settings are SIR (default value) or FIR. IR IRQ Select This option specifies the IR IRQ select for the IR port. The settings are 3 (default value), 4, 5, 9, 10, 11 and 12. IR DMA Select This option specifies the IR DMA select for the IR port. The settings are Disabled, 0, 1 (default value) and 3.
Change Supervisor Password This field allows you to set the Supervisor password. To set the Supervisor password, highlight this field and press the [Enter] key. The following dialog box appears: Enter new supervisor password: Auto Configuration with Optimal Settings The optimal default settings are best-case values that should optimize system performance. To set the configuration, highlight this field and press the [Enter] key.
Chapter 5 The Software Utilities Disks There are two separate procedures on how to install the driver: AutoRun installation and Manual installation. AutoRun Installation Follow the step-by-step procedures on the CD-ROM to execute the “AutoRun” application by selecting the topic of “Driver Installation”. To re-run the “AutoRun” installation, please refer to the procedures on the “Manual Installation” for a more detailed explanation. Installing VGA Display Drivers for Win98SE/2K/ME/XP 37 1.
Installing Hotkey Drivers for Win98SE NOTE: This driver must be installed into your system to fully utilize the hotkey function of Internet, Email, Mute/Unmute, Volume. 1. Insert the CD-ROM Driver into your CD-ROM drive. Click “Start” and Select “Run”. 2. Type the following: D:\Driver\Hotkey Driver\Win98SE\Setup.exe (If D is not your CD-ROM drive, substitute D with the correct drive letter). 3. Click on “Setup” to begin the Installation Wizard. 4.
4. Follow the Wizard’s on-screen instructions to complete the installation. Restart the system. Installing the IR Driver for Win2K/XP/ME 1. Insert the CD-ROM Driver into your CD-ROM drive. Click “Start” and Select “Run”. 2. Type the following: D:\Driver\IR Driver\SETUP.exe (If D is not your CD-ROM drive, substitute D with the correct drive letter). 3. Click on “Setup” to begin the Installation Wizard. 4. Follow the Wizard’s on-screen instructions to complete the installation. Restart the system.
For Win2K/XP After the installation of the IR is completed, the device name found on your system is "Winbond Fast Infrared Controller (DMA)". Double click on the item and select the "Advanced" tab. From the "Value" box, select the "TEMIC" item and click on the "Apply" button. For Win98SE/ME Select the “My Network Places” icon and click your mouse right button to select the “Properties” item. Select the “Winbond Infrared Controller (DMA)”. Double click on the item and select the "Advanced" tab.
Installing the USB 2.0 Driver for Win2K Please follow these instructions to install the USB 2.0 driver. 1. From your screen, click on the "My Computer" icon and use your mouse or touchpad right button to select the "Properties" item. 2. Click on the "Hardware" tab from the "System Properties" window. 3. Click on the "Device Manager" and double click the "Universal Serial Bus (USB) Controller" (denoted by a yellow mark symbol). 4.
Installing the USB 2.0 Driver for WinXP Please follow these instructions to install the USB driver. 1. From your system, click on "Start" and click the "My Computer" icon. Select the "View System Information". 2. Click on the "Hardware" tab from the "System Properties" window. 3. Click on the "Device Manager" and double click the "Universal Serial Bus (USB) Controller" (denoted by a yellow mark symbol). 4. Click the "Update Driver" tab on the "Driver" item. 5.
7. Select the "Browse" button and specify for the designate location of your CD driver. Installing the LAN Driver for Win98SE/ME Please follow these instructions to install the LAN driver: 1. From your screen, click on the "My Computer" icon and use your mouse or touchpad right button to select the "Properties" item. 2. Click on the "Device Manager" tab from the "System Properties" window. 3.
6. Select the “Include this location in the search” item. 7. Select the "Browse" button from the "Include this location in the search" and specify for the designate location of your CD driver. Installing the Modem Driver for Win2K/XP Please follow these instructions to install the Modem driver: 1. From your screen, click on the "My Computer" icon and use your mouse or touchpad right button to select the "Properties" item. 2. Click on the "Hardware" tab from the "System Properties" dialog window. 3.
4. Select the "Browse" button from the "Include this location in the search" and specify for the designate location of your CD driver. Windows 98SE/ME VGA Utilities After you have restarted Windows, open the “Control Panel” and double click on the “Display” icon. From the “Display Properties” window, select the “Settings” tab and click on the “Advanced” tab to enter the "SiS 650/740 Properties" window.
Driver Mode This define the two status of Single , Mirror and Multi Monitor (when an external monitor is connected to your DeskNote computer). When the "Single" is selected, the display can only be seen on the DeskNote LCD panel or external monitor. When the "Mirror" is selected, you can toggle between the LCD and CRT display. Both the LCD and CRT screen display the same image. Display Combination This applies to the display that you prefer to use. The options are VGA1 and LCD2.
This function supports two asynchronous simultaneous display paths with the features of LCD, LCD/CRT or CRT). 1. Click on the “Control Panel” and double click on the “Display” icon. Click on the “Settings” tab to enter the “Display Properties” window. Click on the “Advanced” button. 2. From the “SiS 650/740 Properties” window, click on the “Display Modes” tab 3. Select the "VGA1" or "LCD2" tab by clicking on the button to enable and connect the video display to the external CRT screen. 4.
3. A message is shown on your screen to ask you whether to enable the monitor that you have chosen. Click “Yes” to accept the change. 4. Click the “Apply” tab to run the function and restart the computer. 5. After the system has restarted, your DeskNote LCD screen and the external monitor screen are connected with each other. 6. From the LCD display, open the “Display Properties” and use the cursor to drag it to the right thus moving the image to the external monitor screen.
3D Settings This setting lets you modify the 3D display performance.
D3D Modify the speed and quality of your 3D display. Gamma Correction You can adjust the right color for your window screen by moving the “Brightness” adjustment window to increase or decrease the right resolution for your screen display.
Windows 2000/XP VGA Utilities After you have restarted Windows, open the “Control Panel” and double click on the “Display” icon. From the “Display Properties” window, select the “Settings” tab and click on the “Advanced” tab to enter the "SiS 650/740 Properties" window. You will notice four new entries have been made in the "Utility Manager" window: Gamma Correction, Video Setting, Driver Mode Setting and Product File Information.
Gamma Correction You can adjust the right color for your window screen by moving the “Tint” adjustment window. Adjust the "Brightness" to increase or decrease the right resolution for your screen display.
Video Setting 53
This dialog box has the following scroll bars and buttons for controlling the color components of the video image. Brightness Use this scroll bar to adjust the overall intensity of light emitted by the video display. Contrast Use this scroll bar to adjust the contrast level between the bright and dark areas of the video image. The highter the contrast, the brighter the bright areas and the darker the dark areas, and vice versa.
Driver Mode This define the two status of Single , Mirror and Multi Monitor (when an external monitor is connected to your DeskNote computer). When the "Single" is selected, the display can only be seen on the DeskNote LCD panel or external monitor. When the "Mirror" is selected, you can toggle between the LCD and CRT display. Both the LCD and CRT screen display the same image. Display Combination This applies to the display that you prefer to use. The options are VGA1 and LCD2.
Option 2: Mirror (Simultaneous Display) This function supports two asynchronous simultaneous display paths with the features of LCD, LCD/CRT or CRT). 1. Select the "VGA1" or "LCD2" tab by clicking on the button on "Primary" and "Secondary" to enable and connect the video display to the external CRT screen. 2. Click on the “Apply” tab and you will be ask to keep the new setting. The DeskNote and external monitor/TV screen will now simultaneously display the same image.
Chapter 6 Troubleshooting This chapter describes locating and solving problems that you may encounter while using your computer. Locating a Problem Problems with your computer can be caused by something as minor as an unplugged power cord — or as major as a damaged hard disk. The information in this chapter is designed to help you find and solve minor problems.
message you are getting is from the application or the operating system. Once you know this, you can look in the respective manual for a solution to the problem. Checking Cables and Connections Start by performing a careful visual inspection of the exterior of the computer. If no LEDs are illuminated, make sure that your computer and its peripherals are getting power and communicating with each other properly. To check the power cables, and connections: 1.
alike. The wiring inside the cable may be different. 4. When you are certain that you have power available and all connections are good, turn the computer on again. If the computer still does not start, you may have a hardware problem. The Power-On Self Test The Power-On Self Test (POST) runs every time you turn on or reset the DeskNote. The POST checks memory, the main system board, the display, the keyboard, the disk drives, and other installed options.
If your system does not successfully complete the POST, but displays a blank screen, emits a series of beeps, or displays an error code, consult your dealer. General Hardware Problems A few common hardware problems and suggested solutions are presented in the table below: Problem: Failure in the installation of the Audio driver. Solution: Be sure to first remove the current audio device from your system. Please follow the instruction on the installation of audio driver.
Solution: Reboot the computer and run the BIOS system setup. Confirm the Setup parameters. If the same message is displayed after booting up again, contact technical support for assistance. Problem: The system cannot access the CD-ROM drive. Solution: Check that a CD is properly inserted in the drive. Make sure that you are using the correct program for that kind of CD. For example, the system cannot read a data CD using an audio program. Problem: You cannot operate the printer.
is something that requires the computer to be taken to the shop. Before you call your dealer, however, prepare the following information: • How is your computer configured? Your dealer needs to know what peripheral devices you are using. • What messages, if any, are on the screen? • What software were you running at the time? • What have you done already to try to solve the problem? If you have overlooked a step, your dealer may be able to solve the problem over the phone.
