User's Manual Part 2



  
Correction in Section 11.3, fixed typo in sentence: For WWAN M.2
Modules, only positions 1 and 4 are used.
Updated table to only indicate minimum RX sensitivity limit.
Updated Section Conducted Transmit Power section.
Added CAT 4: DL 150 Mbps, UL 50 Mbps to APAC LTE in Table 3
Deleted LED Blink Status in Table 14
Updated Table 4 and Table 27
Added Humidity Requirement
Removed Quality & Reliability section since this is a requirement of the
ODM.
Correction to: DPR signal includes pull-up, SSIC N/P pin locations, COEX
pin names.
8 2014-06-24
Added IC Canada certification wording.
Section 3.2.1, SIM Design Recommendations - added new section
Section 3.12, Antenna Interface changed connector of the WWAN antenna
cable to iPEX MHF4 from Hirose W.FLT
Section 7, Table 24. Operating Environment changed description for
Operating Temperature to include extreme temperature +55 °C to +70 °C
and added additional description
Section 8.2, deleted Table 27. Electrical Parameters – Host Interface
Signals and replaced it with:
o Table 27. DC Specification for 3.3 V Logic Signaling
o Table 28. DC Specification for 1.8 V Logic Signaling
Section 8.3, Table 29. LTE Power Consumption
o Added additional LTE Use Cases for APAC SKU only - Bands
1, 3, 8, 9, 11, 18, 19, and 21
o Changed standby power to 8 mW
Section 9.6, -
o Table 35. Rx Sensitivity – GSM - added note indicating that
GSM is not supported for APAC SKU.
o Table 36. Rx Sensitivity – UMTS– added note indicating that
the minimum limits reflects that the main and diversity ports are
combined.
o Table 37. Rx Sensitivity – LTE – added note indicating that the
8 LTE bands 2, 4, 5, 7, 13, 17, 20, and 26 is not supported for
APAC SKU
Section 9.7, Antenna Recommendations
Table 38. Antenna Recommendation, added note indicating that the
first 2 recommendations for Input Power are not supported for APAC
SKU.
Table 39. Antenna Recommendation - Bandwidth of Main &
Diversity Antenna - added not indicating that the following 9 RF
Bands 007, 010, 013, 017, 020, 025, 026, 027, and 028 are not
supported by the APAC SKU.
9 2014-11-18
Replaced Requirement with Target in Table 32 to Table 37.
Changes to Table 32. Conducted Transmit Power – 2G
Changes to Table 33. Conducted Transmit Power – 3G
Changes to Table 34. Conducted Transmit Power – LTE
Changes to Table 35. Rx Sensitivity – GSM
Changes to Table 36. Rx Sensitivity – UMTS
Changes to Table 37. Rx Sensitivity – LTE
Changes to Table 38. Antenna Recommendation
10 2014-12-21
Added note to Table 3. WWAN M.2 Module – Data Services
SKU. This is only for generic SW and VZW SW, but not for AT&T SW.
Changes to Section 3.2 USIM Interface
Changes to Section 3.2 USIM Interface
List number 2 and 3
Changes to Table 4. WWAN M.2 Host Interface Signals pins 29, 31, 35,
and 37.
Changes to Table 6. USB SSIC - ICP Interface
Changes to Table 33. Conducted Transmit Power – LTE
Changes to Table 4. WWAN M.2 Host Interface Signals pins 29, 31, 35,
37, and 67.
Changes to Table 36. Rx Sensitivity – LTE
