User's Manual Part 2



  
 
Revision Date Changes
0 2013-05-20 First issue
1 2013-07-09 •
Update setting for Pin 21 on the host interface. This signal is not connected.
• Updated pin names of pins 1, 21, 69, and 75 in Table 4 and Table 19 to
simply reflect HW Configuration use.
• Updated Table 24 to indicate configuration pins 1, 69, and 75 are tied to
GND.
• Rename section 3.6 Coexistence Interface to In-Device Coexistence
Interface. Additional information on the Inter-device coexistence support was added.
• Updated section 4.1.3 System Trace Tool Section.
• Updated Figure 5 – RF Engine for WW SKU.
• Add further information USB LPM to USB section
• Added information on Seamless Roaming & Wifi Off-load – SIM_EAP,
SIM-AKA under Other Requirements
• Added information on Antenna Design Guidelines under Other
Requirements.
2 2013-07-29 RF bands updated
3 2013-08-26 Updating on RF bands
Updated section 3.5 and 3.4.5
Updated temp range
4 2013-09-09 HN930-DC product was removed from portfolio
5 2013-09-15 Main & Diversity antenna positions have been swapped.
Updated documentation accordingly, Figure 6 and Figure 10.
Updated WWAN M.2 Mechanical drawings, Figure 14 through Figure 17.
Updated Card_power_ON_OFF description for UltraBook in Table 9.
Updated comments in Table 15 regarding the DPR#/SAR signal.
Updated SIM DTECTED signal to indicate an external pull-up.
Updated Platform Block Diagrams to show DPR# signal is connected to an
EINT pin (not GPIO) on XGOLD.
Identified Audio Signals on host interface in Table 4. Previously these were
simply defined as Reserved.
Updated VBAT requirements in Table 24 and Table 25.
6 2013-11-20
Regulation section was updated
Adding support for UMTS Band 6 to M.2 APAC SKU (see Table 2).
Updated 3G RF Band support for APAC Module, supported bands are 1, 8,
11, and 19. (see Table 2)
Added Measured Values for 2G/3G Rx Sensitivity Table 31 and Table 32.
Update Measured Value and changed header name in Rx Sensitivity LTE
Table 33
Modified supply voltage lower spec for Ultra book in Table 24.
Update Table 4, Table 6, Table 26 voltage levels for USB and SIM pins.
Added LTE conditions and added Table 33.
7 2014-04-10
Added SSIC to ICP interface. Updated RESET signal definition. Updated
Antenna figures.
Updated Conducted Transmit Power requirements, Table 32.
Section 2.2, Table 4
Changed UIM signals pins 30, 32, 34, 36
Replaced dash with underscore in signal names.
Changed supply voltage for Antenna Tuning Signal
(ANTCTL*) from (1.7 V – 2.6 V) to 1.8 V.
Section 3.5, Table 20 changed supply voltage for Antenna Tuning Signals
(ANTCTL*) from (1.7 V – 2.6 V) to 1.8 V.
Section 3.11, Table 25 correction to both no connect pins and key slot pins.
Section 8.2, Table 27
o Changed the max voltage to 3.0 V for WAKE_WWAN# signal
o Changed Typ voltage and max voltage for the Antenna Tuning
Signals to 0/1.8 V and 2.3 V respectfully
