User's Manual Part 2



  
LN930-AP (APAC SKU only)
EARFCN
LTE
Band
Duplex Modulation Bandwidth
(Hz)
Min Rx
Sensitivit
y Limit
(dBm)
Low
Channel
Middle
Channel
High Channel
1 FDD QPSK 10 -96 50 320 550
3 FDD QPSK 10 -96 1250 1678 1900
8 FDD QPSK 10 -96 3525 3625 3750
9 FDD QPSK 10 -96 3850 3975 4099
11 FDD QPSK 10 -96 4800 4850 4899
18 FDD QPSK 10 -97 5900 5925 5950
19 FDD QPSK 10 -97 6050 6075 6100
21 FDD QPSK 10 -96 6500 6525 6549
26 FDD QPSK 10 -97 8740 8865 8989
GSM not supported for APAC SKU
Main and Diversity ports are measured separately. Combining both antenna ports
increases sensitivity by 3 dB. Table 36. Rx Sensitivity – UMTS reflects both ports
combined.
Table 37 is a generic view that includes all LTE bands for Rx sensitivity. The APAC
SKU does not include LTE Bands 2, 4, 5, 7, 13, and 17.
